Required batteries for the
helicopter:
Rated output: DC 3.7 V / 0.67 Wh
Batteries: 1 x 3.7 V rechargeable
LiPo battery (integrated)
Capacity: 180 mAh
Charger:
Power supply: DC 5 V of USB port of
a PC or USB hub
Rated output: 4.2 V / up to 500 mA
1 HELICOPTER
1A Gegenläufige Rotorblätter
1B Paddelstange
1C Heckrotor
1D LED­Leuchten
1E Ladebuchse
1F ON-/OFF-Schalter
3A Unscrew and remove the cover
3B Insert 6 x 1.5 V AA batteries and pay attention to the polarity, as shown in the
battery compartment.
3C Close the battery cover and secure with the screw.
Attention: The battery and motor must cool down for 15 to 30 minutes before char­
ging and after every flight. Otherwise they can be damaged. The charging process
must be constantly monitored. Always ensure that the charging process takes place
on a fireproof surface in a fire-resistant environment.
1. Switch off the helicopter (Switch 1F) and the remote control (Switch 2A).
2. Plug the USB charger into a USB hub or a USB port on a computer (4A).
If the charger is ready for operation, the LED on the top illuminates red.
3. Now insert the connector on the charger into the underside of the model
(charging port 1E) (4B). The charging process begins automatically.
12

TECHNICAL DATA

3 INSERTING BATTERIES

4 CHARGING THE HELICOPTER
Battery requirement for the remote
control:
Power supply:
DC 9 V
Batteries: 6 x 1.5 V "AA"
2 REMOTE CONTROL
2A ON/OFF switch
2B Thrust controller
2C Antenna
2D Trim adjustment
2E Controller for forwards and back­
wards flight as well as rotation
2F ON/OFF button for LED
2G Button for ‚Turbo' function
