4. The Power LED on the charger goes out during the charging process and illuminates
red when the battery is full (4C). After charging, disconnect the battery from the
charger and pull the charger plug out of the USB interface.
The helicopter can fly for approx. 5-7 minutes after a charge time of
approx. 40 minutes.
Warning notice: The LiPo battery does not normally heat up while charging. If it
should become warm or even hot and/or changes to the surface begin to appear,
immediately discontinue the charging process!
You can also charge your helicopter with the remote control:
• Switch off the remote control and the helicopter.
• The plug for the charge cable is located on the back of the remote control (4D).
Remove the cover and then carefully plug the cable into the charge socket of the
helicopter (4E). The plug must be gently inserted into the charging socket – DO NOT
USE FORCE. If the plug is not correctly inserted into the charging socket, the helicopter
may become damaged and, under certain circumstances, become an injury risk.
Switch on the remote; the power LED blinks red. Slowly move the thrust controller
(2B) to maximum and then back to its starting position to activate the remote
control; the power LED will begin to blink quickly. This process lasts for approx.
3 seconds. Now the LED continuously illuminates green.
• The charging process is complete as soon as the LED is illuminated red.
• After the charging process, switch the power switch to „OFF" and disconnect the
charge cable from the helicopter.
The thrust controller (2B) must point down before being switched on (5A). Then set the
remote control's ON/OFF switch (2A) to „ON" (5B). The power LED begins to blink.
Now set the helicopter's ON/OFF switch (1F) to the „ON" (5C). Place the helicopter on
the ground so that the tail points toward you (5D).
Activate the remote control by slowly moving the thrust controller to maximum and then
back to its starting position; the power LED will begin to blink quickly. This process lasts
for approx. 3 seconds. The helicopter is ready to start when the headlamp is permanent­
ly illuminated red.
6 TRIM ADJUSTMENT OF THE CONTROL
The correct trimming is a basic requirement for achieving fault­free flying from the
helicopter. Its adjustment is simple, but it requires some patience and a feel for it.
Please observe the following instructions precisely: Carefully move the thrust controller
(2B) up and raise the helicopter approximately 0.5 to 1 metre in altitude.
6A If the helicopter quickly or slowly rotates clockwise by itself...
If the helicopter begins to automatically rotate clockwise, rotate the trim adjustment
(2D) anti­clockwise until the helicopter no longer rotates on its own.
Required batteries for the
helicopter:
Rated output: DC 3.7 V / 0.67 Wh
Batteries: 1 x 3.7 V rechargeable
LiPo battery (integrated)
Capacity: 180 mAh
Charger:
Power supply: DC 5 V of USB port of
a PC or USB hub
Rated output: 4.2 V / up to 500 mA
Battery requirement for the
remote control:
Power supply:
DC 9 V
Batteries: 6 x 1.5 V "AA"
5 START PREPARATION
