Example In the case of a length measurement by means of encoder and
cyclometer, where the circumference of the cyclometer measures
200 mm and the encoder supplies 500 pulses per revolution, the
measurement is to be displayed in mm.
The scaling factor is calculated as follows for this example:
Scaling factor =
➜ Press key
Read
The scaling factor SF is displayed.
➜ The lower display indicates „SF".
➜ Enter the scaling factor via the keys
Modify
The setting range from 0.0001 to 999.99 is attained by shifting the
decimal point. Select the decimal point via
➜ Press key
By pushing
www.baumer.com
Circumference
Pulses
or .
.
or again, the current count is re-displayed.
200
= = 0.4000
500
.
and shift using
NE134
.
