4. Technical data

Motor rating ............................................... 900 W
Motor speed ......................................... 2950 rpm
AC motor ................................ 220-240 V ~ 50 Hz
Insulation material class .......................... Class B
Protection type ............................................. IP54
Cut length .............................................. 920 mm
Jolly length .............................................. 920 mm
Max. workpiece thickness 90° .................. 36 mm
Max. workpiece thickness 45° .................. 29 mm
Table size ...................................... 890 x 475 mm
Working height: ...................................... 700 mm
Diamond wheel ........................... Ø 200 x Ø 25.4
Weight (without cutting wheel and
with an empty water container) .... approx. 43.5 kg
Max. operating weight
(with cutting wheel and a
fi lled water container) ...................... approx. 85 kg
Max. weight/dimensions
of the workpiece ....................56 kg / 92 x 60.5 cm
A load factor of S2 30 min (intermittent periodic
duty) means that you may operate the motor
continuously at its nominal power level (900 W)
for no longer than the time stipulated on the spe-
cifi cations label (30 minutes ON period). If you fail
to observe this time limit the motor will overheat.
During the OFF period the motor will cool again to
its starting temperature.
Danger! Sound and vibration
The noise emission values were measured in ac-
cordance with EN 61029.
With-load operation
L sound pressure level ..................... 62,5 dB(A)
pA
K uncertainty ............................................. 3 dB
pA
L sound power level ....................... 75,5 dB(A)
WA
K uncertainty ............................................. 3 dB
WA
Keep the noise emissions and vibrations to a
minimum.
•
Only use appliances which are in perfect wor-
king order.
•
Service and clean the appliance regularly.
•
Adapt your working style to suit the appliance.
•
Do not overload the appliance.
•
Have the appliance serviced whenever ne-
cessary.
•
Switch the appliance off when it is not in use.
GB
•
Caution!
Residual risks
Even if you use this electric power tool in
accordance with instructions, certain resi-
dual risks cannot be rules out. The following
hazards may arise in connection with the
equipment's construction and layout:
1. Lung damage if no suitable protective dust
2. Damage to hearing if no suitable ear protec-
3. Health damage caused by hand-arm vib-

5. Before starting the equipment

Before you connect the equipment to the mains
supply make sure that the data on the rating plate
are identical to the mains data.
Warning!
Always pull the power plug before making
adjustments to the equipment.
•
•
•
Unfolding the base frame (Fig. 2)
To set up the equipment on its feet (1), press the
latching button (a) and lower the respective feet
(1) until they latch in the intended position. To fold
up the feet (1), proceed in reverse order.
Fitting the cooling water pump (Fig. 4A - 4C)
•
•
Notice!
To guarantee proper operation, the cooling water
hose (14) must not be kinked during installation.
www.sidirika-nikolaidi.gr
- 23 -
Wear protective gloves.
mask is used.
tion is used.
rations if the equipment is used over a pro-
longed period or is not properly guided and
maintained.
The equipment has to be set up where it can
stand securely.
All covers and safety devices must be cor-
rectly attached before the machine is used for
the first time.
The cutting wheel must rotate smoothly.
Place the cooling water pump (13) - with the
suction cups pointing down - into the contai-
ner (a).
Then fasten the hose to the intended posi-
tions as shown in Fig. 4B and 4C.
