Item Qty. Part No. Description
1
1
600267
Base, (Black)
2
1
10884401 Wheel Axle
3
2
600056
Wheel, 3.5"
4
1
FR918381 Top Pole Section - Silver
1
FR908381 Top Pole Section - Black
5
1
FR918383 Middle Pole Section - Silver
1
FR908383 Middle Pole Section - Black
6
1
901059
Bottom Pole Section - Silver
1
901056
Bottom Pole Section - Black
7
2
203679
Bolt 3/8-16 x 2 Long
8
4
204961
Bolt, Hex Head, 3/8-16 x 0.625 Long
9
4
203063
Nut, Nylock, 3/8-16
10
2
901063
Tank Strut -Silver
2
901006
Tank Strut - Black
11
1
203147
Bolt, Hex Head, 5/16-18 x 4" Long
12
9
203218
Washer, Flat, 3/8 I.D.
13
2
203099
Nut, Nylock, 5/16-18
14
2
908256
Backboard Bracket
15
6
205528
Bolt, Hex Flange, 5/16-18 x 1 Long
16
8*
203100
Nut, Hex Flange, 5/16-18
17
4
204962
Bolt, Hex, 5/16-18 x .625 Long
18
1
202739
Bolt, Hex, 5/16-18 x 1.75 Long
19
2
108843
Wheel Bracket
20
4
201436
Spacer 0.530 I.D. x 0.73 O.D. x 0.75 Long
21
1
204583
Label, Height Adjustment and Moving
1
FR204583 Label, Height Adjustment and Moving, French
22
1
600137
Cap, Pole Top 3.5"
23
2
600272
Cap, Base, Screw Cap, Large, 5.5" Dia.
24
1
203617
Cap, Base
25
1
Rim
PARTS LIST - See Hardware Identifier
13
Item Qty. Part No. Description
26
1
Net
27
1
108163
Pole Mount Bracket
28
2
203053
Bolt, Carriage, 5/16-18 x 4" Long
29
2
208266
Spacer 0.53 I.D. x 1.13 Long
30
1
206049
Spring, Black, Slam Jam
31
1
200318
Bracket, Reinforcement, Slam Jam
32
1
900033
Bracket, Slam Jam
33
1
206048
T-Bolt, 3/8-16 x 3.25 Long
34
1
206990
Reinforcement Bracket
35
1
203470
Washer, Flat, Slam Jam
36
1
203795
Nut, Special
37
1
204872
Label, Height Indicator
38
1
938153
Tube Assembly w/Handle,
Adjustment, Outer - Silver
1
918153
Tube Assembly w/Handle,
Adjustment, Outer - Black
39
1
918174
Tube, Adjustment, Inner - Silver
1
908174
Tube, Adjustment, Inner - Black
40
6
206340
Nut, Nylock, 1/2-13
41
2
928173
Elevator Tube, Lower - Silver
2
908173
Elevator Tube, Lower - Black
42
2
905808
Elevator Tubes, Upper - Silver
2
904808
Elevator Tubes, Upper - Black
43
6
206279
Bolt, Hex, 1/2-13 x 6-1/2 Long
44
1
204838
Spring, Elevator
45
2
208452
Gasket, Screw Cap
46
1
20279501 Label, NBA Logo
47
1
200504
Cover, Red
200503
Cover, Black
48
2
200520
Screw, #8 x 3/4" Long
49
1
205527
Pole Pad
50
1
108181
Plate, Pole Mounting
* You may have extra parts with this model.
