Overview

1 2
7 8

INSTALLATION

Installing/Replacing the lamp

Before replacing the lamp, unplug mains lead and let the lamp cool down (approx. 5 minutes).
During the installation do not touch the glass-bulbs bare-handed! Please follow the lamp manufacturer's
notes!
Do not install lamps with a higher wattage! Lamps with a higher wattage generate temperatures the device
was not designed for. Damages caused by non-observance are not subject to warranty.
For the installation, you need you need one PAR-64 pressed-glass lamp with up to max. 1000 W or a raylight
reflector with a GY-9.5 lamp socket with up to max. 500 W.
3 4 5 6
DANGER TO LIFE!
Only install the lamp with the device switched off!
Unplug from mains before!
The lamp has to be replaced when it is damaged
or deformed due to the heat!
(1) Housing cover
(2) Mounting-bracket
(3) Extension spring
(4) Tube
(5) Hole for safety rope
(6) Clip-to-hold clamps
(7) Silicone cable
(8) Fixation screw
(9) Color filter frame
(10) Hole for safety rope for color filter frame
9 10
CAUTION!
