The symbol
between light-output and the illuminated surface must be more than the given value.
This device is only allowed for an installation via the mounting bracket. In order to safeguard sufficient
ventilation, leave 50 cm of free space around the device.
The housing must never touch surrounding surfaces or objects.
Make sure that the area below the installation place is blocked when rigging, derigging or servicing the
fixture.
Always fix the fixture and the color filter frame with an appropriate safety-rope.
The maximum ambient temperature T
Operate the device only after having become familiarized with its functions. Do not permit operation by
persons not qualified for operating the device. Most damages are the result of unprofessional operation!
Never use solvents or aggressive detergents in order to clean the device! Rather use a soft and damp cloth.
Please use the original packaging if the device is to be transported. Make sure that you pack the device in
the original state.
Please consider that unauthorized modifications on the device are forbidden due to safety reasons!
If this device will be operated in any way different to the one described in this manual, the product may suffer
damages and the guarantee becomes void. Furthermore, any other operation may lead to dangers like short-
circuit, burns, electric shock, lamp explosion, crash etc.
WEEE Directive
When to be definitively put out of operation, take the unit(s) to a local recycling plant for a disposal which is
not harmful to the environment. Do not dispose of as municipal waste. Contact your retailer or local
authorities for more information.

DESCRIPTION OF THE DEVICE

Features

Short version
Rugged aluminum housing
•
Strong aluminum mounting bracket with hole for fixing the obligatory safety rope
•
Heat-resistant fixing screw for "bombproof" fixing
•
The screw is protected against turning it too far out
•
4 clip-to-hold clamps with spring locks for comfortable opening of the color filter frame
•
Safety grille (splinter protection) is integrated in the tube
•
Internally blackened tube for precise light output
•
Strong brass clamps with extension spring for safe hold and for quick opening of the rear housing
•
cover
Protection grille on the rear housing cover - complies with CE-regulations
•
Comes fully-wired with black silicone cable, stable earthing in the housing and directly clamped
•
ceramic socket
Delivered with color filter frame
•
With strong cable tension relief
•
Well-suited for easy installation of our Raylight reflectors with matching connector (GX16)
•
Simple mounting: connect with ceramic socket - ready!
•
Power plug has to be ordered separately
•
determines the minimum distance from lighted objects. The minimum distance
= 45° C must never be exceeded.
a
