Disposal
7 Disposal
Disposal of electrical and electronic appliances:
EC-wide regulations for the disposal of electric and
electronic appliances which have been defined in the EC
Directive 2002/96/EC and in national laws have been
effective since August 2005 and apply to this instrument.
Common household appliances can be disposed of using
special collecting and recycling facilities. However, as this
instrument has not been registered for household usage,
it must not be disposed of through these means.
The instrument can be returned to your national Dräger
Sales Organisation for disposal. Please do not hesitate to
contact the above if you have any further questions on this
issue.
24
8

Technical Data

Extract: see the Technical Handbook for details
Ambient conditions:
During operation and -20 to +50 °C (-20 to +40 °C with type
storage 180AAHC NiMH single cells and T3 alkaline
batteries)
700 to 1300 hPa
10 to 90 % (short-term up to 95%) relative
humidity
Protection class IP 54 for instrument with sensors
Alarm volume Typically 90 dB (A) in 30 cm distance
Operation time
Alkaline battery Typically 150 hours under standard conditions
NiMH rechargeable Typically 150 hours under standard conditions
batteries
Dimensions approx. 130 x 48 x 44 mm (H x W x D)
Weight approx. 220 to 250 g
CE marking: Electromagnetic compatibility
(Directive 2004/108/EC)
Explosion protection
(Directive 94/9/EC)
Approvals: (see "Notes on Approval" on page 246)
Sensor data: See data sheets for the sensors used.
1 The Technical Handbook, the Instructions for Use/data sheets for the
sensors used, and the Dräger CC-Vision PC software are included on CD.
See also the enclosed Instructions for Use and data sheets for the sensors
used. The Instructions for Use/data sheets of the sensors used can also be
downloaded from the following Internet address: www.draeger.com
