Insert the switched off instrument into the charger.
Display LED on the charger:
Charge
Fault
Full
To maintain the lifetime of the batteries, charging is only performed
within a temperature range of 5 to 35 °C. Outside this temperature
range, the charging is automatically interrupted and resumes
automatically after the temperature is within the range again.
The charging time is typically 4 hours.
A new NiMH power pack reaches its full capacity after three
complete charge/discharge cycles.
Never store the instrument for extended periods without being
connected to a power source (maximum of 2 months) because the
internal buffer battery will drain.
Dräger X-am 5100
3.1.2 Replacing the Batteries / Rechargeable Batteries
WARNING
!
Danger of explosion!
Do not replace the batteries / rechargeable batteries in areas
where there is a danger of explosion.
Do not throw used batteries into fire or try to open them by force.
Dispose of the batteries in accordance with national regulations.
Batteries / rechargeable batteries are part of the Ex approval.
Only the following types may be used:
Alkaline batteries – T4 – (not rechargeable)
Duracell Procell MN1500
Alkaline batteries – T3 – (not rechargeable)
Varta Powerone 4006
Varta Powerone 4106
Panasonic Powerline LR6
NiMH rechargeable batteries – T3 – (rechargeable)
GP 180AAHC (1800)
max. 40 °C ambient temperature.
1. Switch off the instrument if necessary (see "Switching off the
instrument" on page 18).
2. Loosen the screw (2.0 mm hexagon socket) on the power pack
and remove the power pack.
3. Replace the alkaline batteries with new ones or the rechargeable
NiMH batteries with charged ones – ensure correct polarity.
4. Completely replace the T4 power pack (with sealed rechargeable
batteries, Order No. 83 18 704/83 22 244).
5. Insert the power pack into the instrument and tighten the screw,
the instrument switches on automatically.
After replacing the power pack T4, it is recommended that
a complete charging is carried out.
