OPERATING INSTRUCTIONS
VOLTAGE TESTER "VC-65"
ITEM NO.: 1377526
INTENDED USE
The two-pole voltage tester can be used to measure and display DC and AC voltages in an electrical
low-voltage circuit. The product also has an acoustic and visual circuit indicator as well as a resistance
measurement and an RCD test function. Power is supplied by two batteries of type
AAA/Micro included in the delivery.
The voltage tester complies with the standard for two-pole voltage testers of 12 - 1000 V/AC and
12 - 1200 V/DC, CAT III 1000 V, CAT IV 600 V according to EN 61243-3:2010/EN 60529 as well as
protection class IP64 (dust and spray water). The product is suitable for use in dry or damp conditions.
Use during rain or other precipitation is not permitted. The voltage tester is designed for use by electrically
skilled persons using personal protective equipment.
The measuring instrument must not be operated when the battery compartment is open.
Measuring under adverse ambient conditions such as dust and flammable gases, vapours or solvents is
not permitted.
Always observe the safety instructions and all other information included in these operating instructions.
This product complies with the applicable national and European requirements. All names of companies
and products are the trademarks of the respective owners. All rights reserved.
DELIVERY CONTENT
• Voltage tester
• 2x batteries of type Micro/AAA
• 2x protective plastic covers
• 2x 4 mm adapter to open probe tips
• Operating instructions
EXPLANATION OF SYMBOLS
T he lightening flash symbol in a triangle warns against the risk of an electric shock or
interference with the electrical safety of the device.
An exclamation mark inside a triangle refers to important. notes in the operating instructions.
The arrow symbol indicates special information and advice on operating the device.
SAFETY INSTRUCTIONS
The warranty will expire in case of any damage caused by the failure to follow these
operating instructions! We assume no liability for any resulting consequential damage!
We assume no liability for any damage to property or personal injuries caused by
improper use or non-compliance with the safety instructions! In such cases, the warranty
will be null and void.
• The unauthorised conversion and/or modification of the product is not permitted for safety and
approval reasons (CE). Do not disassemble the product.
• This product is not a toy. Therefore, be especially careful when children are around. Use the
product where it is out of the reach of children.
• Never use the product immediately after it has been taken from a cold room to a warm one.
The condensation that forms can ruin the product under certain circumstances.
• Avoid the following adverse conditions at the location of installation and during transport:
- Extreme cold or heat, direct sunlight
- Dust or flammable gases, fumes or solvents
- Strong impacts, blows
• Do not leave packaging material carelessly lying around, since it could become a dangerous
plaything for children.
• H andle the product with care, it can be damaged by impacts, blows, or accidental falls, even
from a low height.
• Never touch the measuring tips or a measuring point during the measuring process. There is
a risk of electric shock.
• Never touch areas outside of the marked handling area during a measurement.
• D o not use in the immediate proximity of strong magnetic or electromagnetic fields or
transmission aerials. These can affect the measurement.
• Prior to and after each measurement, check your instrument and the measuring leads for
damages. Never take any measurements if the protecting insulation is defective or the
measuring instrument is damaged otherwise.
• Be especially careful when dealing with voltages higher than 50 V/AC or 75 V/DC. Even at
such voltages you can get a life-threatening electric shock if you come into contact with live
electric wires.
• The measuring instrument is suitable for use in dry or damp conditions. Avoid use in a damp
or wet environment. Always ensure that the probe tips are perfectly clean. Dirty or even
corroded test clips can lead to an incorrect measurement.
• The test probes must only be touched at the handles provided for this purpose. Otherwise,
there is danger of an electric shock.
VERSION 09/15
• Never exceed the highest permissible voltage values. If the stated values are exceeded, the
product becomes damaged and poses a hazard that can be fatal. (See chapter "Technical
data").
• T he recovery time as specified in "Technical data" must always be adhered to. Otherwise, the
product could be damaged.
• T he voltage values specified are nominal voltages.
• If the neutral wire (N) or the earth wire (PE) is interrupted, no reading is shown.
• The measuring instrument must only be used within the permissible ambient conditions (see
chapter "Technical data").
• Always attach the measuring tip cover if you are no longer using the device.
• Store the measuring instrument in a dry place, protected against dust, if you are no longer
using it.
• When using the voltage tester in the measurement category CAT III and CAT IV, it is
recommended to attach the plastic protective covers to the test probes to decrease the length
of the free contact tips. This reduces the risk of a possible short circuit during testing.
• CAT I
• CAT II
• CAT III
• CAT IV
GENERAL BATTERY INSTRUCTIONS
• Batteries should be kept out of the reach of children.
• D o not leave batteries lying around in the open; there is a risk of them being swallowed by children or
pets. If they are swallowed, consult a doctor immediately.
• Leaking or damaged batteries can lead to caustic burning of the skin. Therefore, use suitable protective
gloves.
• B atteries must not be short-circuited, opened or thrown into fire. There is a risk of explosion.
• M ake sure that the polarity is correct when inserting the batteries (pay attention to plus/+ and minus/–).
DESCRIPTION OF SYMBOLS
V AC DC
12/24/50/120/230/400/600/1200
k Ω
Hz
INSERTING / REPLACING BATTERIES
Disconnect the voltage tester from the respective measurement object.
Hold both measuring tips together. If no signal sounds or an empty battery symbol appears on the display,
the batteries must be replaced. To protect your safety, attach the two plastic covers/measuring tip covers.
For this purpose, loosen the screw (18) using a small Phillips head screwdriver. Now, carefully pull the
battery compartment (17) downwards along the cable. Remove the empty batteries from the measuring
instrument, where applicable, and insert new batteries of the same type (see "Technical Data") into the
battery compartment observing the correct polarity. The use of rechargeable batteries is not permitted. We
recommend to use alkaline batteries. They guarantee a long service life. Slide the battery compartment
back upwards until you feel it click in place and carefully close the compartment with the screw (18).
Measurement category I for measuring electrical and electronic devices that are
not directly supplied with mains voltage (e.g. battery-operated devices, etc.)
Measurement category II for measuring electrical and electronic devices that are
directly supplied with mains voltage via a mains plug.
Measurement category III for measuring building installations (e.g. mains sockets
or sub-distributors).
Measurement category IV for measuring the source of low-voltage installations
(e.g. main distribution, main transfer point of the utility company) and outdoors.
Alternating current (AC)
V/AC: Alternating voltage
V/DC: Direct current
Display of rated voltage range in volt (V)
Direct current positive potential DC
Direct current negative potential DC
Electrical resistance in kilo-ohm
Electrical frequency (Hertz)
Single-pole phase display 100 - 1000 V
as well as warning for hazardous voltage (>50 V/AC, >120 V/DC).
Operation also possible with flat batteries or without batteries
Symbol for continuity check
Battery symbol for used battery
Conformity symbol, CE-approved
Device and equipment for working under voltage. Personal
protective measures required.
Protection class 2 (double or reinforced insulation/protective
insulation)
