27-channel mode
Channel Value
Derby 1
1 000-255
2 000-255
3 000-255
000-009
4
010-255
000-004
005-127
5
128-133
134-255
Spot 2
6
000-255
7 000-255
8 000-255
000-009
9
010-255
10 000-255
Spot 3
11
000-255
12
000-255
13 000-255
000-009
14
010-255
15
000-255
Derby 4
16
000-255
17
000-255
18 000-255
000-009
19
010-255
000-004
005-127
20
128-133
134-255
Laser
000-004
005-009
21
010-255
000-004
005-009
22
010-255
000-004
005-127
23
128-133
134-255
Strobe-LEDs
000-004
24 005-009
010-255
000-004
25 005-009
010-255
000-004
005-009
26
010-255
000-004
27 005-009
010-255
www.eurolite.de
Function
Brightness red 0-100 %
Brightness green 0-100 %
Brightness blue 0-100 %
Brightness red, green and blue 0-100 %
Sound-controlled strobe effect
Strobe effect slow → fast (30 Hz)
All colors on
No rotation
Clockwise rotation slow → fast
Brightness red 0-100 %
Brightness green 0-100 %
Brightness blue 0-100 %
No function
Strobe effect slow → fast (30 Hz)
No function for spots or
rotation when operating a derby at this position
Brightness red 0-100 %
Brightness green 0-100 %
Brightness blue 0-100 %
No function
Strobe effect slow → fast (30 Hz)
No function for spots or
rotation when operating a derby at this position
Brightness red 0-100 %
Brightness green 0-100 %
Brightness blue 0-100 %
Brightness red, green and blue 0-100 %
Sound-controlled strobe effect
Strobe effect slow → fast (30 Hz)
All colors on
No rotation
Clockwise rotation slow → fast
Red laser off
Red laser on
Red laser strobe effect slow → fast
Green laser off
Green laser on
Green laser strobe effect slow → fast
No rotation
Clockwise rotation slow → fast
No rotation
Anti-clockwise rotation slow → fast
Strobe LED 1 off
Strobe LED 1 on
Strobe LED 2 slow → fast
Strobe LED 2 off
Strobe LED 2 on
Strobe LED 2 slow → fast
Strobe LED 3 off
Strobe LED 3 on
Strobe LED 3 slow → fast
Strobe LED 4 off
Strobe LED 4 on
Strobe LED 4 slow → fast
