Prior to use
No-Picture Problem
If no picture is displayed on the monitor even after the following remedial action is taken, contact your local dealer.
1. Check the Power indicator.
Symptom
No picture
* For the setting of the brightness, contrast and gain, please refer to the User's Manual on the CD-ROM.
2. Check the error message that remains on the screen.
These messages appear when the input signal is incorrect even if the monitor is functioning.
Symptom
Installation Setting/Adjustment
Status
Power indicator does not light.
Power indicator is lighting blue.
Power indicator is lighting
orange.
Status
The input signal is not received.
The signal frequency is outside
the specification. Incorrect
signal frequency is shown in
red.
Troubleshooting
Possible cause and remedy
Check whether the power cord is connected
correctly.
Press .
Set each adjusting value in <Brightness>,
<Contrast> and <Gain>* to higher level.
Switch the input signal with
Operate the mouse or keyboard.
Touch the panel surface.
Turn on the PC.
Possible cause and remedy
The message shown left may appear, because
some PCs do not output the signal soon after
power-on.
Check whether the PC is turned on.
Check whether the signal cable is connected
properly.
Switch the input signal with
Select an appropriate display mode using the
graphics board's utility software. Refer to the
manual of the graphics board for details.
fD : Dot Clock
(Displayed only when the digital signal
inputs)
fH : Horizontal Frequency
fV : Vertical Frequency
.
.
