CAUTION
Operating noise
Damage to hearing
► Use ear protection!
Vibration emission value a
directions) and uncertainty K measured in accord-
ance with EN 60 745:
Screwing
Drilling in metal
Impact drilling into concrete
Uncertainty
Declared total value of vibrations was measured
according to standard measure method and can
be used for comparison one powertools with the
others.
Declared total value of vibrations can be used for
preliminary setting of exposition.
Warning:
Emission of vibrations during real operating can
be different from declared total value of vibrations
depending on specifi c real conditions.
To protect operating person shell be provide safety
measurement, that evaluate the exposition under
the real conditions (here are included all parts of op-
erating cycle, switch of mode and idle run mode).
5

Commissioning

5.1 Changing the battery pack
Removing the battery pack
Press and hold the two buttons [2-1].
Slide the battery pack forwards to remove.
Inserting the battery pack
Slide the battery pack onto the retainer on the
underside of the handle shown in Fig. [2] until it
engages.
5.2 Charging the battery pack
► The battery pack is delivered partially charged.
Charge the battery pack completely before using
for the fi rst time.
To charge the battery pack, slide all the way onto
the retainer [3-2] on the charger.
► To remove, slide the charged battery pack from
the charger in similar fashion.
The charger automatically detects the type of the
inserted battery (NiCd, NiMH or LiIon).
A microprocessor controls the charging process in
line with the charging state, temperature and volt-
age of the battery pack. If a warm NiMH battery
pack (> 37 °C) is inserted, the pack is charged with
a reduced charging current and will take longer to
charge.
The LED [3-1] on the charger indicates the respec-
tive operating status of the charger.
14
(vector sum for three
h
a < 2.5 m/s
h, S
a = 5.6 m/s
h, D
a = 12.4 m/s
h, ID
K = 1.5 m/s
LED yellow – lit continuously
Charger is ready to use.
LED green – fl ashing quickly
Battery pack is charged to maximum capacity.
LED green – fl ashing slowly
Battery pack is charged with reduced current, LiIon
is charged to 80 %.
LED green – lit continuously
Battery pack is fully charged, conservation charg-
2
ing active.
2
LED red – lit continuously
2
Battery temperature is outside the permitted range.
2
LED red – fl ashing
General fault display, e.g. incomplete contact, short
circuit, battery pack faulty, etc..
5.3 Wall mounting
There are two elongated holes on the back of the
BC 3 for mounting the charger to a wall using two
screws (e.g. round head or fl at head screw with
shank diameter of 5 mm).
Insert the two screws into the wall at a distance
of 96 mm from one another and leave the screw
heads protruding approx. 4 mm.
6

Machine settings

► Setting must be done only when the machine
is turned off and will be accepted only after
restarting it.
6.1 Changing the direction of
rotation
The right/left switch [1-3] changes the direction
of rotation.
Move switch from right to left = clockwise rotation;
Move switch from left to right = anticlockwise ro-
tation.
6.2 Changing gear
► Always switch off the machine before changing
gear!
You can change gear using the gear switch [1-5].
6.3 Fastening
Move the switch [1-6] to the torque setting.
Setting on 1
Setting on 12
The machine switches off when the preset torque
is reached and an acoustic signal sounds. You must
release and press the ON/OFF switch [1-2] again
to start the machine.
Upon levels 1 – 12, a decreased number of rota-
tions can be set.
6.4 Drilling
The selector switch [1-6] is set to the drill symbol
marking = maximum torque.
= low torque
= high torque
