12 – ROUTINE MAINTENANCE AND PRECAUTIONS
a) It is recommended to clean the tank periodically by pulling it out carefully by its proper handle and by putting
the water tubes into it again being careful not to bend them.
b) Clean up the steam tube and the frothing spout regularly. The spout can be removed by pulling it down.
c) Use a normal damp cloth to clean both the spout and the pipe.
d) Do not leave the machine outdoor.
e) Do not immerse the machine in water.
f) Use the machine only under adult control and keep away from children.
Attention: damages due to the emptiness of the machine water circuit voids war-
ranty; it recommended to read the instruction booklet carefully and to control the
tank (1) water level regularly.
8
A
B
C
D
E
Picture 1
C
A
B
FIG. 3
13 – TECHNICAL DATA
Power supply: 230-240V 50Hz ; 120V 60Hz
Power: 950W
Warming time: about 6 minutes
Pressure pump: 15 bar
Tank capacity: 2,7 litres
Dimensions (HxLxD): 330x240x290 mm
Weight: 10 kg
12.1 – CLEANING OF THE TURBO STEAM NOZZLE
Always clean properly with a wet cloth the end of the turbo steam nozzle (6) after use
to avoid its obstruction and altering of the beverages flavour. Once every now and then
clean it more specifically (picture 1):
• Remove the spout cover (E) pulling it downwards.
• Unscrew the threaded nut (A) turning it anticlockwise until the steam nozzle
comes out (8).
• Clean the injector (D) in warm water to get rid of possible milk rests and clean
with a needle the hole of the steam nozzle.
After cleaning please assemble it as follows:
• Insert the threaded nut (A), the gummy rings (B) and (C) on the steam nozzle
(8), insert the injector (D) and screw the threaded nut (A) clockwise in order to fix
the injector.
• Insert the nozzle cover (E) pushing it upwards.
12.2 – CLEANING OF THE AUTOMATIC CAPPUCCINO MAKER
Apart from cleaning it every time it has been used, please clean it every now and
again more accurately (picture 3):
D
• Unscrew the threaded nut (A) turning it anticlockwise until the steam nozzle comes
out.
• Remove the cover ( D), the pin ( C ), and the pipe ( B ), wash then all in fresh water.
Rinse everything thoroughly with warm water to remove possible milk rests and
reassemble the Automatic Cappuccino maker again.
