7. Wettkampfaufgaben (Task) definieren
In this section we will present an example of how to set a task in your LIVE-SD.
7.1.
Wettkampfaufgaben (Task) definieren
Consider the task represented in Abbildung 7.1, and detailed in Table 7.1
Cylinder type
Time
LAUNCH
12:00:00 PM
START
01:00:00 PM
CYLINDER
CYLINDER
CYLINDER
CYLINDER
END OF SPEED
SECTION
GOAL
05:00:00 PM
Tabelle 7.1 – Task Beispiel
In order to set up the task in your LIVE-SD you should go trough the following steps:
1. Delete any existing task on the LIVE-SD (see Section 4.1.2);
2. Add to the task, in the right order LAUNCH, WHALEB twice, SHEEP, HEBRON,
GOOSEN, and finally WHALEL twice. The LIVE-SD will automatically assume LAUNCH
as the takeofi since it is the first waypoint on the list. The first WHALEB will be used as
Start, and the last WHALEL will be used to define the landing deadline. As waypoints
are entered their properties can be edited as you enter each waypoint;
3. On the task list, select the first occurrence of WHALEB and edit it. Change the
waypoint type to Start Out, set the distance to 2.000km, and the start time to 13:00.
(Note that all times are in the 24 hour clock). Beware, that it is very important that the
first occurrence of WHALEB be set as Start, otherwise the LIVE-SD will assume that
WHALEB needs to be completed before the start gate, and that is not what is required
for this task. Nothing needs to be changed for the second occurrence of WHALEB since
the default values are the ones wanted.
4. Edit each of the waypoints SHEEP, HEBRON, and GOOSEN and set the distance to
match the wanted one. All these waypoints are cylinders which is the default type.
5. Edit the first occurrence of WHALEL and change its type to End of Speed Section,
the Size to 2.000km, and leave the Time with 00:00, and Cone with 0.0.
6. Edit the second occurrence of WHALEL and change its type to GOAL. The radius
does not need to be changed since the radius is by default 400m. Continuously
pressing the ENTER bottom will make the cursor jump to the next parameter which is
the time. Time should be set to 17:00 which is the goal close time.
Waypoint name
Map name
LAUNCH
toff
WHALEB
TP1
WHALEB
TP2
SHEEP
TP3
HEBRON
TP4
GOOSEN
TP5
WHALEL
TP6
WHALEL
TP6
77
Cylinder size
2 km
400 m
3 km
6 km
2 km
2 km
400m
