SWITCH:
Turn ON / OFF the AC power.
out
COAX
r P
Name Function Description
AC POWER IN
SWITCH
COAX out
RF
Headphone
(AUDIO)L/R IN
VIDEO
SCART
VGA IN
PC Audio IN
HDMI
YPbPr
Common Interface
Getting Started
P b Y
Connect to power supply 100 - 240V AC 50/60HZ
Turn on/off the AC power
Output to Audio amplifier
Connec to Aerial, Tuner input 75 Ohm Coaxial Socket. t
Connect headphone
Audio signal input for AV
Connect to the Video output of external equipment
Connect to the scart input / output of external equipment
Connect to the PC VGA output to display PC graphics
PC audio input
Connect to the HDMI socket of your DVD or Satellite Box
:
Connect to the YPbPr output on external equipment.
CI slot ( Pay as you view card slot )
100mm
4
Connections
10
10
