CARDIOSTRONG CST-BC50 Bedienungsanleitungen Seite 44

Nr. Bezeichnung (ENG)
95 cross Bolt
96 Screw
97 water bottle
98 cross screw
99 Adjustable round wheel
100
101 bushing
102 Anti-loose nut
103 magnet
104 cross screw
105 Left crank
106 Left pedal
110
111 cross bolt
112 round-head cross screw
117 tension cable
118 buffer
119 round-head cross screw
120 screw
121 screw
/ open-end wrentch
/ Inner six angle cross wrench
/ Inner six angle wrench (M4)
44
Pin
bolt
Material Spezifizierung
Q235A M5x0.8x12L
10# ST4.2x1.4x20L
Q235A
10# M5*0.8*15L
Q235A+ABS D59*M10*40L
ABS D6*26.5*7.7
F101J D20*D14*11.5T
Q23A 3/8"-26UNFx6.5T
NDFEB 39.5*10*25
Q235A
M5x0.8x10L
170Lx9/16"-20BC
1015A
PP+Q235A JD-22A 9/16"
M5*0.8*10L
M5*0.8*10L
10# ST4x20L
D1.5*200L
NBR
40.5*28.5*6T
10#
ST4*1.41*25L
35# 1/4"-20*40L,8.8grade
PVC D28*17(M6)
Q235A 155*30*5T
35# M6,8.8grade
Q235A
M4*68L
Anz.
1
19
1
2
2
3
1
2
8
2
1
1
2
2
2
1
1
2
4
4
1
1
1
BC50
