lIpo battery chargIng

The quadcopter is equipped with a LiPo
battery
3.7 V 1-cell 100 mAh LiPo battery.
1. The LiPo battery supplied is in the fuselage of the Quadcopter.
Remove the LiPo battery from the model.
2. Connect the flight battery to the USB charger connection. The
indicator lamp on the USB plug glows and goes out when the
charging process is completed.
Never leave the battery and charger unattended during charging;
after charging disconnect the battery from the charger!

reaDy to Start

Now you can take off! But before it is important, that you read the complete manual.
Start station
1
Switch the quadcopter on and put it on the launcher, which must
be positioned on a level surface (see picture).
3
Move the Throttle lever to the top and after back to lower position.
Your model is ready to fly now.
ON/OFF
switch
2
Push the ON/OFF knob one time. The Status-Led begins to flash.
23 // GB
