PREPARATIONS

Basic System

VF BRIGHT
USER 1 USER 2 USER 3
ND FILTER
2
1
MENU
STATUS
WHT.BAL
AUTO AUTO
AUDIO
CH-1 LEVEL CH-2
ON OFF
POWER REC
HD CAMERA RECORDER
GY-HD250/GY-HD251
PROMPTER OUTPUT
terminal
Monitor
Power is supplied by the Remote Control Unit RM-P210 via the 26 pin camera cable when in-use. If the Remote Control Unit
RM-P210 is not in-use, use AC power adapter.
View Finder
DM-3106 (Astrodesign)
V-R70P-HAD (Marshall Electronics)
VF OUTPUT
terminal
(BNC × 3)
STUDIO KIT
KA-HD250
Tripod
Dolly
View Finder
VF-P400
Conversion plug
VF OUTPUT
terminal
Headset
(Round 20-Pin)
DT109 (Beyerdynamic)
INTERCOM terminal
DC cable
IA-60a, VL-2PLUS (IDX)
DC INPUT terminal
RM terminal REMOTE cable
TALLY CALL FULL AUTO F1 F3
SHUTTER
BARS F2 F4
GAIN
INTERCOM
LEVEL
Remote Control Unit
RM-P210
Headset
DT109 (Beyerdynamic)
AC Power Adapter
REMOTE CONTROL UNIT RM-P210
MENU/SHUTTER GAIN WHITE MASTER BLACK IRIS POWER
PAINT AUTO
STEP W.BAL
HIGH B
I
SHUTTER VARIABLE
MID A AUTO
MENU PUSH-ON PUSH-ON R B PRESET MANU
LOW
O
DOWN UP DOWN UP CLOSE OPEN
9
