Graphics adapter
Monitor
USB controller
Sound adapter
Keyboard
Mouse
USB FlashDrive
Ports
Test strategy
Tests were conducted according to a strategy for hardware that is based on the test program developed by Karl Bunnell,
Novell Cool Solutions Feature (http://www.novell.com).
Test results
The results of the tests specified below report whether an error occurred in each individual step of the test strategy. The
table below gives an overview of all tests for the Manufacturer's Declaration.
Test
Installation
Automatic device detection Validates the capability of the Linux distribution to detect all important
Boot manager
Network
Kernel compatibility
DVI/VGA
DP
X Server
Sound adapter
Port
Pointing device
Keyboard
RAID adapter
2
Intel Xeon 3-1200 v3 Intel HSW Graphics Chipset Accelerated VGA BIOS
Integrated 22" touch panel display, 1920 × 1080 pixels
Intel 8Series/C220 Series Chipset EHCI USB Controller, 2 ×
Intel 8Series/C220 Series Chipset xHCI USB Controller
Intel Xeon 3-1200 v3/4thGen High Definition Audio Controller
Intel 8Series/C220 Series Chipset High Definition Audio Controller
USB SIMATIC PC (My3000)
Integrated touch panel, USB Microsoft
Siemens SIMATIC IPC USB FlashDrive 8 GB
6ES7648-0DC50-0AA0
Siemens SIMATIC IPC USB FlashDrive 16 GB
6ES7648-0DC60-0AA0
2 × COM (serial type 16550A)
•
LPT (parallel PC style: PCSPP, TRISTATE, EPP)
•
Description
Validates the installation of the Linux distribution of Novell openSUSE
13.1 Installations DVD from the internal DVD/CD ROM drive.
For details, see "Section 2.1 Notes on installing and configuring"
devices, for example:
Processors
•
RAM
•
All connected drives (fixed and removable)
•
USB ports
•
Mouse
•
VGA video adapter
•
Ethernet controller
•
Validates that the Linux distribution can be booted with selected
hardware using the "Grub" boot manager.
Validates the functionality of the LAN channel (Ethernet controller) with
DHCP, fixed IP addresses and remote administration (VNC).
Verifies that the selected hardware configuration works without error with
the selected Linux distribution.
Verifies proper function of monitor adapter across selected resolutions
and color depths.
Verifies proper X Server operation.
Tests the operability of the audio systems and audio hardware.
Verifies proper function of the system serial port and parallel port.
Verifies proper function of pointing device and its components (buttons,
wheel, etc.)
Validates all keys, control keys, function keys, etc.
–
Result
Successful
Successful
Successful
Successful
Successful
Successful
Successful
Not applicable, no
ports available
Successful
Successful
Successful
–
SIMATIC IPC677D "Suitable for Linux"
A5E34147575-AA, 05/2014
