6.2 Programming with

Programming with Programming with Programming with
Programming with
memory car memory card d d d d memory car memory car memory car
All basic functions as per 6.1
are supported.
Additional functions:
Luminaire description for
approx. 1000 luminaires,
alphanumeric with max. 20
characters/luminaire
Programming of the SKU for
circuit or individual
monitoring
Programming the SKU for
non-maintained light,
maintained light
Switching by means of
timer 1, timer 2, DLS 1,
DLS 2 and TLS
Keeping a logbook acc. to
VDE 0108/10.89 and
memorizing on the memory
card for min. 2 years.
6.2.1 Texts describing the
luminaires
Basic menu:
Info Device
Manual Test
Block&Reset Alarms <
Controller Setup
Logbook
3 x
Basic Setup
Device Setup Line
Update ZB/US Line
Return
ZB96/US96 01↑↓
Device Setup
SKU Setup
Cursor 3 x right, Enter opens
setup of the SKU
ZB/US96 01,SKU1/1→←↵
BGT1:_ _ _ _ _ _ _ _
BGT2:
BGT3:
BGT4:_ _ _ _ _ _ _ _
BGT5:_ _ _ _ _ _ _ _
= SKU inst. X= Fail
Inquires information
about SKU from the
panel.
Circuit1↑↓
BL:_ DL:_ T1:_ T2:_
DLS 1:__ 2:__ TLS:__
M e n u
Switched by Timer?
Cursor Right jumps to
the SKU selection
End
Circuit1↑↓
BL:X DL:_ T1:_ T2:_
DLS 1:__ 2:__ TLS:__
Switched by timer?
< < < < <
Acknowledges selec
tion.
Installed↑
↵
↵
3 x
Selects rack (1-
5)
Selects SKU on
a rack.
Selects circuit
No. (1-4) of the
SKU.
Calls (X) or se
lects (-) or
counts 01-32
(DLS/TLS)
Passes to the
next selection
point or goes
back.
