Safety notes

Safety notes
2. Safety notes Safety notes Safety notes
The CG controller shall be
operated for its intended
purpose and in perfect con-
dition!
When working on the safety
lighting plant, it must be
ensured that the system is
disconnected from the volt-
age! The different types of
power supply in normal and
emergency operation have
to be observed.
Before the initial operation
of the controller, the ZB 96
system will have to be
checked in accordance with
the instructions of section
„Installation" in the ZB 96
operating instructions
(CEAG No. 400 71 346 035).
When performing any work
on the controller, the na-
tional safety rules and regu-
lations for prevention of ac-
cidents as well as the
safety instructions included
in these operating instruc-
tions marked with ! must be
observed.
3. 3. 3. 3. 3. Conformity with Conformity with Conformity with Conformity with Conformity with
standar standards standar standar standar ds ds ds ds
Conforming to: VDE 0108/
10.89, DIN/VDE 0805/11.93,
IEC 950. Designed, manufac-
tured and tested acc. to DIN EN
ISO 9001.
4. T 4. T ec ec ec echnical data data data
4. T 4. Tec 4. T data data

4.1 Technical data

Supply voltage: 230 V AC ± 10 %
or 24 V DC
current consumption
(230 V): max. 80 mA
(24 V): max. 450 mA
Indicator
contact: 1 x UM, 24 V
0,5 A; freely
programmable
EGA signal inputs
EGA-interface card
type CEAG: 1... 32 ZB 96
panels
Cable length: max 2500 m
unshielded
cable
(3 x 1,5 mm²)
LON-BUS signal input
LON FTT 10 interface card for
connection to the building
management.
Printer connection
Printer interface: DB 25
Printer driver: HP-Deskjet
(PLC 3), IBM-Proprinter
Display panel
Illuminated display,
alphanumeric, 4 x 20 char-
acters
Mechanical data
Insulation class: II
Protection category acc.
to EN 60527: IP 65
Ambient
temperature: -5°C..+40°C
Rel. humidity: 0 - 95 %, no
condensation
Supply
terminals: max. 2.5 mm²
Weight: approx. 1.8 kg
Dimensions /mm
(L x W x D) : 184 x 240 x 112
4.2 Brief description/Field 4.2 Brief description/Field 4.2 Brief description/Field
4.2 Brief description/Field 4.2 Brief description/Field
of application of application
of application of application of application
The CG controller is suitable for
monitoring and controlling
CEAG type ZB 96 safety light-
ing systems. One controller can
operate up to 32 plants.
