Product description

4.2. LED status display

Status
1. Stand-by & unconnected
2. Connected mode
3. Pairing mode
4. Switch on
5. Switch off
6. Battery status
7. Charging
8. Charging complete
9.Reset
32
LED display
Blue LED lights up every 3 seconds
Blue LED lights up every 5 seconds
Red and blue LEDs light up alternately
Blue LED lights up for 1 second
Red LED lights up for 1 second
Indicates the battery status after
the system is switched on:
· over 50%, blue LED lights up for 1 second
· between 10%-50%, red and blue LEDs light
up at the same time for 1 second
· under 10%, red LED lights up for 1 second
LED lights up RED
LED lights up blue
Red and blue LEDs light up at the same time
