LH VIEW OF FURY 6 TABLE SAW CONFIGURATION
6
4
1. ON/OFF TRIGGER SWITCH (Inside handle)
2. ON/OFF LATCHING SWITCHES
3. CUTTING HANDLE
4. TABLE TOP
5. AUXILIARY LOWER BLADE GUARD
6. UPPER BLADE GUARD
www.evolutionpowertools.com
8
7. RIP FENCE
8. PUSH STICK
9. MOUNTING HOLE (2 at the front and
2 under the stabilising arms)
10. CUTTING HEAD LATCHING PIN
(Not shown in this view)
