Installation
5.) If you want to use a jig saw for cutting out the circle, you
should drill a suitable hole first in which the jig saw blade fits
easily in.
Please take care of drilling the hole within the circle.
6.) Prepare the ceiling cut-out by means of a sharp knife (suitable
for the most lightweight walls) or a (electrical) jig saw (suitable for
most other wall- or ceiling-materials)
7.) The result is shown in this picture. The cable ends with a
length of approx. 35-40 cm will come out of the hole.
8.) Connect the loudspeaker cables to the jacks of the In-Ceiling
loudspeaker that are on the rear side of the speaker.
The correct polarity is important here (marked wire = positive pole,
must be connected to red terminal, negative pole = must be
connected to black terminal). Press on the terminal and insert the
cables through the hole on the side of the terminal and release the
terminal again.
13
