Function Access
mode
1
Reference colour values, saved in the sensor (incl. tolerances)
Colour vector 1 R/W
Colour vector 2 R/W
Colour vector 3 R/W
Colour vector 4 R/W
Colour vector 5 R/W
Measured colour values
Measured R
colour values
R = Read
1
W = Write
The colour portions and intensity can be values between 0 and 1023. The total of the red, green and blue colour
2
portions is 1023; i.e. the blue portion which is not sent can be calculated from: 1023 minus green portion minus red
portion.
INFORMATION
If an index which is not available is used for writing or reading, the sensor answers with the
error message „Subindex not available".
8.5

Integration in the Engineering System

Parameterization of BFS 26K is made in the Engineering System by means of IODD file (IO-Link Device Description).
The IODD file suitable for colour sensor BFS 26K is available for download in the internet at:
www.balluff.com
42 42
Index Data
format
dez. hex.
41 3x
IntegerT (16)
42 3x
IntegerT (16)
43 3x
IntegerT (16)
44 3x
IntegerT (16)
45 3x
IntegerT (16)
2
46
Bit assign- Range
ment
6 byte
6 byte
6 byte
6 byte
6 byte
16 byte
No. 862090 E Edition J15; Replaces edition 1312; Subject to modification
Montage- und
Bedienungsanleitung
Remark
Colour values channel 1
Colour values channel 2
Colour values channel 3
Colour values channel 4
Colour values channel 5
Byte 0: process data
Byte 1: not used
Byte 2+3: red
Byte 4+5: green
Byte 6+7: level
Remaining bytes: not used
