CAB THARO A8 Serviceanleitung Seite 73

Part-No.
5902075 Flush Screw DIN965-M4x8-4.8-galZn
5902084 Screw DIN7985-M3x5-4.8-H-galZn
5902085 Screw DIN7985 M3x4-4.8-H-galZn
5902089 T humbscrew DIN653-M4x12-5.8-galZn
5902098 Screw DIN7985 M2.5x6-galZn
5902112 Screw DIN7985 M3x25-galZn
5902129 Screw KB22x6-WN1412-galZn-cB
5902133 Flush Screw DIN965-M4x10-4.8-H-galZn
5902141 Hex Standoff Nut 4-40UNC/M3
5902144 Screw DIN7985 M3x5-8.8-galZn
5902178 Screw DIN912-M6x20-8.8-galZn
5902222 Screw UNC4-40x3/8-Z-galZn
5902224 Flush Screw DIN7991-M4x12-8.8-galZn
5902240 Flush Screw DIN7991-M5x14-8.8-galZn
5902241 Screw DIN7984-M4x10-galZn
5902252 Screw DIN965/DIN7500-M3x6-Z-galZn
5902253 Screw DIN7985/DIN7500-M4x8-Z-galZn
5902256 Screw DIN923-M4x12-5.8-galZn
5902280 Screw DIN7985/DIN7500-M4x20-Z-galZn
5902288 T humbscrew DIN464-M3x8-galZn
5902293 Flush Screw DIN7991-M3x16-8.8-galZn
5902304 Flush Screw DIN7991-M4x6-8.8-galZn
5902330 Bolt DIN427-M5x10
5902352 Screw DIN7985/DIN7500-M4x6-Z-galZn
5902353 Screw DIN923-M4x8-galZn
5902370 T humbscrew M4x10
5902372 Bolt DIN931-M5x90-8.8-galZn
5902501 Nut DIN934-M4-galZn
5902505 Nut DIN934 M3-8-galZn
5902506 Nut DIN934-M2.5-8-galNi
5902508 Nut DIN934 M5-8-St-galZn
5902510 Nut DIN934 M4-Ms galNi
5903003 Washer DIN125-A4.3-galZn
5903004 Washer DIN125-A3.2-galZn
5903006 Washer DIN988-10x16x0.1 blank
5903009 Washer DIN9021-3.2-galZn
1) Standard Version
2) Special Version with Spreading Axle
3) Securing Device
4) Part of Present Sensor (Option)
A 8
De scri pti on Q ty./machine Position
2 A2/33
2 A3/43
2 A10/1
2 A7/11
2 A3/41
2 A3/37
6 A2/7
2 A9/6
3 A10/5
4 A10/9
2 A2/20
2 A3/6
2 A3/23
3 A8/15
1 A7/20
2 A2/43
3 A7/5
4 A7/2
11 A2/28
2 A5/9
9 A2/35
2 A6/4
4 A2/39
2 A10/13
1 A10/24
2 A9/10
6 A2/31
2 A7/13
1 A2/36
2 A3/2
1 A10/18
2 A5/18
1 A3/3
4 A2/14
8 A2/23
2 A2/40
1 A5/4
4 A10/21
2 A5/11
1 A5/5
2 A2/3
4 A2/38
1 A3/4
10 A4/10
2 A10/16
2 A2/22
1 A3/18
2 A3/24
2 A6/2
3 A8/16
2 A6/15
4 A2/13
8 A2/24
Note
2)
4)
3)
4)
2)
A19
