KEYPAD

1. ON/OFF LED
2. ON/OFF horizontal and vertical laser line

POWER SUPPLY

Put in 3 x AA Alkaline batteries into the battery case (4) (take care to polarity) and
close battery compartment.

SET UP / MULTI-FUNCTIONAL MOUNT

Fix the instrument on the multi-functional mount by using the 1/4" adapter.
To move the instrument up or down on the mount declamp the knob (7).
For locking the desired position of the instrument tighten the knob again.
Use of the laser on a tripod.
Use of the laser with the magnets.
Use of the laser with strap attachment.
1
2
EN
C
D
E
13
