Parts List – Spare Parts List
Cambridge II Order No. 9903
Technical data: Issue: 01. 04. 2017
• stimulating most of users muscles
• Elastic-Rope-System
• 4- way adjustable resistance
• comfortable seat with slide rollers
• foldable for save space
• Computer showing time, beats, beats per minute and approx calories
• Max. body weight 120 kg
Space requirement approx L 173, W 44, H 53 cm
Space requirement foldable approx L 110, W 44 x H 108 cm
items weight = 15Kg
Illustration Designation
No.
1 Main frame
2 Front stabilizer
3 End cap
4 Bolt
5 Curved washer
6 Spring washer
7 Cap nut
8 Bolt
9 Washer
10 Pedal
11 Screw
12 Computer
13L Cover Left
13R Cover Right
14 Bolt
15 Washer
16 Bushing
17 Bearing
18 Wheel
19 Idler wheel
20 Fixed sleeve
21 Nylon nut
22 Grip
23 End cap
24 Axle
25 Bearing
26 Wheel
27 U-shaped washer
28 Rope lock
29 Plug
30 Handlebar
31 Foam grip
32 Rope
33 Star grip screw
34 Bolt
35 Bushing
Please check after opening the packing that all the parts shown
in the following assembly steps are there. Once you are sure that
this is the case, you can start assembly.
Please contact us if any components are defective or missing, or
if you need any spare parts or replacements in future:
Internet service- and spare parts data base:
www.christopeit-service.de
Adresse: Top-Sports Gilles GmbH
Friedrichstraße 55

42551 Velbert

Telefon: +49 (0) 20 51 / 60 67-0
Telefax: +49 (0) 20 51 / 60 67-44
e-mail: info@christopeit-sport.com
www.christopeit-sport.com
This Product is created only for private Home sports activity
and not allowed to us in a commercial or professional area.
Home Sport use class H/C
0 5 10 15 20 25 30 35 40
Quantity Dimensions
mm
1
1
4
M8x65 2
8//19 2
for M8 6
M8 2
M12x130 2
12//24 4
2
4x18 10
1
1
1
M8x62 4
8//16 19
12x8x8.5 4
608 16
2
2
1
M8 7
2
3
1
6201 2
1
1
2
2
1
2
1
1
M10x80 1
12x8x20 3
12
50 60 70 80 90
Attached to ET number
illustration No.
33-9903-01-SI
1 33-9903-02-SI
2+47 36-9903-06-BT
2 39-10001-CR
4 39-9966-CR
4+46 39-9864-VC
4 39-9900-CR
1+10 39-10504
8 39-9986-CR
8 36-9903-05-BT
13 39-10187
13 36-9903-03-BT
1+13R 36-9903-01-BT
1+13L 36-9903-02-BT
1+18+19 39-10436
14+33+46+53 39-9862-CR
14 36-9903-07-BT
18+54 36-9903-08-Bt
14 36-9903-09-BT
20 36-9903-10-BT
1 36-9903-11-BT
14+53 39-9818-CR
24 36-9903-12-BT
1 36-9903
25 36-9903-13-BT
26 36-9903-14-BT
25 36-9903-15-BT
30 36-9903-16-BT
32 36-9903-17-BT
32 36-9903-18-BT
32 33-9903-03-SI
30 36-9903-19-BT
1+30 36-9903-20-BT
45 36-9903-21-BT
1+45 39-10055-CR
53 36-9903-22-BT
100 mm
