PREPARATION

FILTER INSTALLATION

To maintain the quality of the filters, they are installed in the main unit and packed in
plastic bags. Be sure to remove the filters from the plastic bags before using the unit.
1
1
Remove the filters
1
Remove the Front Panel.
Pull the bottom of the Front Panel.
2
Remove the Filter Support.
Pinch the two tabs and lift to remove.
Up side Tabs
3
Remove the Active Carbon
Filter and HEPA Filter.
4
Remove the Active Carbon
Filter and HEPA Filter from
the plastic bags.
Be sure to remove the power plug from the wall outlet.
Tabs
Active Carbon Filter
HEPA Filter
Main Unit
Active Carbon Filter
E-6
Front Panel
HEPA Filter
