6. Technische Daten Compact XL
Inputs (note 1)
Channel 1 Jack 1⁄4" (6.35 mm), unbalanced input
Sensitivity: 38 mV (-28 dBV)
Impedance: 2.2 Megohm
Noise (note 3): 1.8 µV (-115 dBV),
A-weighted
Phantom power:
9 V at 'ring' terminal (max. 100 mA).
Switchable.
High/low switch: 10 dB attenuator
Channel 2 Jack 1⁄4" (6.35 mm) + XLR combo socket
Line mode:
Unbalanced mono jack input only
Sensitivity: 64 mV (-24 dBV)
Impedance: 1 Megohm
Noise (note 3): 2.8 µV (-111 dBV),
A-weighted
Mic mode:
XLR (balanced), stereo jack (balanced), or
mono jack (unbalanced) input
Sensitivity: 5.4 mV (-45 dBV)
Impedance: 1.2 k (balanced use),
or 4.2 k (unbalanced use)
Noise (note 3): 2.2 µV (-113 dBV),
A-weighted
Phantom power: 48 V (XLR only)
Voice filter: -10 dB at 270 Hz (referred to 10 kHz)
Clip indic. Threshold: 8 dB below actual clipping
(Ch. 1 and 2)
Aux in Stereo cinch (RCA), L + R mixed and added
pre-master.Sensitivity: 2 x 44 mV (-27 dBV),
adjustable Impedance: 22 k
Return
Effect return for parallel effect loop. Effect
signal is added pre-master.
Mono jack, unbalanced
Relative gain of send-return loop: +2 dB
Sensitivity (note 1): 760 mV
Impedance: 20 k
Outputs (note 2)
Tuner Mono jack, unbalanced, 310 mV (-10 dBV),
post equalizer, pre effects, pre master
Line out Mono jack, unbalanced, 1.5 V (+3 dBV),
post master
DI out XLR, balanced, adjustable 0–130 mV (-18 dBV),
post equalizer, pre effects, pre master
Send
Mono jack, unbalanced, 1.25 V (+2 dBV)
if "pan" control is set fully clockwise, post
eqalizer, pre effects, pre master
Headphones Stereo jack
Output power: max. 100 mW / 32 ohms
Input sensitivity: 30 mV at channel 1 input for
2 x 50 mW / 32 ohms
Internal speaker is muted while headphones
are connected.
For stereo headphones only. You should not
connect anything with a mono jack plug!
www.aer-amps.com
Compact XL - 2012_08_DE
10
Footswitch Stereo jack,
tip = internal effect on/off,
ring = external effect on/off,
sleeve = ground.
Equalizer
Channel 1 Colour: -3 dB at 700 Hz,
and +10 dB at 8 kHz
Bass: ±8 dB at 100 Hz (shelf type)
Middle: ±2 dB at 600 Hz
Treble: ±8 dB at 10 kHz (shelf type)
Channel 2 Bass: ±8 dB at 100 Hz (shelf type)
Treble: ±11 dB at 10 kHz (shelf type)
Effects
Built-in effects 1 reverb 1 (short)
2 reverb 2 (long)
3 delay (320 ms)
4 chorus
Power
Power amp
200 W / 8 ohms (THD < 1%),
discrete bipolar transistor design
Limiter threshold RMS limiter 100 W
Analog signal Subsonic filter, low distortion RMS limiter
processing
Speaker 2-way system, 8" (200 mm) low-midrange
+ 1" (25 mm) dome tweeter, light-weight
neodymium alloy magnets
Mains power AC 100, 120, 230, or 240 V models,
50–60 Hz, max. 450 W
Mains fuse 5 x 20 mm
slow 3.15 A for 230 and 240 V models
slow 6.3 A for 100 and 120 V models
General
Cabinet 12 mm (0.5") birch plywood
Finish
waterbased acrylic, black spatter finish
Dimensions Height: 320 mm (12.6")
Width: 326 mm (12.9")
Depth: 282 mm (11.1")
Weight 10 kg (22.1 lbs)
Notes:
1. Input sensitivities refer to 100 watts into 8 ohms at full gain and
volume settings, neutral tone control settings and 1 kHz sine-wave
test signal.
2. Output levels refer to 50 mV / 1 kHz input at channel one, unless
stated otherwise.
3. Equivalent input noise voltage obtained by measuring noise
voltage at the speaker and dividing by the effective voltage gain of
the amplifier for the respective input. Full gain and volume settings,
neutral tone control settings, input shorted, frequency range
20 Hz – 20 kHz.
Specifications and appearance subject to change without notice.
