6. Technische Daten

Line Jack socket ¼" (6.35 mm), sensitivity 150 mV, RIN
> 7.5k, optional phantom power 9 V on ring, max.
100 mA (requires internal jumper setting)
Mic Jack / XLR combo socket, balanced or unbalanced,
sensitivity 7 mV, RIN = 1.4k (balanced use), RIN
= 7.5k (unbalanced use), phantom power 48 V
(XLR only), integrated voice fi lter -12 dB at 260 Hz
(referred to 10 kHz)
Aux Stereo cinch socket, sensitivity 2 x 75 mV,
RIN > 20k
CLIP INDICATOR Headroom
INSERT POINTS
Insert pre eq Stereo jack, 150 mV (note 2)
tip = send, ring = return
Insert post eq Stereo jack, 150 mV (note 2)
tip = send, ring = return
TONE CONTROL
Bass ±8 dB at 100 Hz (shelf type)
Treble ±11 dB at 10 kHz (shelf type)
POWER
Power amp 60 W / 4 ohms, DMOS, monolithic IC
Limiter threshold 50 W
Analog signal processing
Subsonic fi lter, harmonics enhancer, adaptive
peak limiter (anti-clipping)
Speaker 8" twin cone fullrange speaker
Mains power
100, 120, 230, or 240 V AC models (see label),
50–60 Hz, max. 120 W
Mains fuse 5 x 20 mm slow 1 A for 230 and 240 V models
slow 2 A for 100 and 120 V models
GENERAL
Cabinet 0.6" (15 mm) birch plywood
Finish waterbased acrylic, black spatter fi nish
Dimensions 10.2" (260 mm) high
13.0" (330 mm) wide
10.2" (260 mm) deep not including rubber feet
Weight 16.5 lbs (7.5 kg)
www.aer-music.de
AG 8 active monitor - 2012_10_DE
2
12 dB
Notes:
1. Input sensitivities refer to 50 watts into 4 ohms at full gain
and volume settings, neutral tone control settings, and 1
kHz sine-wave input signal.
2. Output levels refer to 50 mV / 1 kHz at line input.
3. XLR assignment:
Pin 1 = Ground
Pin 2 = +
Pin 3 = –
Specifi cations and appearance subject to change without
notice.
