Use Of The Fryer; Use Of The Control Panel - FriFri Basic Plus & Elegance S Plus Bedienungsanleitung

5 Use of the fryer

5.1 Control panel

5.2 Use of the control panel

Working thermostat
After connection of the fryer to the supply network, the control panel must be
initialized by pressing the red "Reset" button.
Press the "ON" Button to put the control panel under tension.
The green LED light indicates that the control panel is ready to use.
The „Standby" position is also the fat melting cycle (FMC). This position allows
to heat up slowly to 60°C. The heating element switch on and off during this
cycle in order to melt fat and to heat up fat and oil without smoke and increase
the lifetime of the fat and oil.
The orange LED „Heating phase" is blinking during the FMC mode.
The LED becomes fix as soon as the end temperature is reached.
Start / Stop
Oil pump
Reset / Initializing
Safety thermostat
Control light
heating element
ON / OFF
Button
