Fühlerkennlinien
BALCO
BALCO
Temperatur
Widerstand
Klemmen-
[°C]
[Ω]
spannung [V]
-30,0
397
0,471
-29,0
399
0,473
-28,0
401
0,475
-27,0
403
0,477
-26,0
404
0,479
-25,0
406
0,481
-24,0
408
0,483
-23,0
410
0,485
-22,0
412
0,488
-21,0
413
0,490
-20,0
415
0,492
-19,0
417
0,494
-18,0
419
0,496
-17,0
421
0,498
-16,0
423
0,500
-15,0
425
0,502
-14,0
426
0,504
-13,0
428
0,506
-12,0
430
0,508
-11,0
432
0,510
-10,0
434
0,513
-9,0
436
0,515
-8,0
438
0,517
-7,0
440
0,519
-6,0
442
0,521
-5,0
444
0,523
-4,0
445
0,525
-3,0
447
0,528
-2,0
449
0,530
-1,0
451
0,532
0,0
453
0,534
1,0
455
0,536
2,0
457
0,538
3,0
459
0,541
4,0
461
0,543
5,0
463
0,545
6,0
465
0,547
7,0
467
0,549
8,0
469
0,551
9,0
471
0,554
10,0
473
0,556
11,0
475
0,558
12,0
477
0,560
13,0
479
0,563
14,0
481
0,565
15,0
483
0,567
16,0
485
0,569
17,0
487
0,572
18,0
489
0,574
19,0
491
0,576
82
Temperatur
Widerstand
Klemmen-
[°C]
[Ω]
spannung [V]
20,0
493
0,578
21,0
495
0,581
22,0
497
0,583
23,0
499
0,585
24,0
501
0,587
25,0
503
0,590
26,0
506
0,592
27,0
508
0,594
28,0
510
0,596
29,0
512
0,599
30,0
514
0,601
31,0
516
0,603
32,0
518
0,606
33,0
520
0,608
34,0
522
0,610
35,0
524
0,613
36,0
527
0,615
37,0
529
0,617
38,0
531
0,620
39,0
533
0,622
40,0
535
0,624
41,0
537
0,627
42,0
539
0,629
43,0
542
0,631
44,0
544
0,634
45,0
546
0,636
46,0
548
0,638
47,0
550
0,641
48,0
553
0,643
49,0
555
0,646
50,0
557
0,648
51,0
559
0,650
52,0
561
0,653
53,0
564
0,655
54,0
566
0,658
55,0
568
0,660
56,0
570
0,662
57,0
572
0,665
58,0
575
0,667
59,0
577
0,670
60,0
579
0,672
61,0
581
0,675
62,0
584
0,677
63,0
586
0,679
64,0
588
0,682
65,0
590
0,684
66,0
593
0,687
67,0
595
0,689
68,0
597
0,692
69,0
600
0,694
Temperatur
Widerstand
Klemmen-
[°C]
[Ω]
spannung [V]
70,0
602
0,697
71,0
604
0,699
72,0
607
0,702
73,0
609
0,704
74,0
611
0,707
75,0
614
0,709
76,0
616
0,712
77,0
618
0,714
78,0
621
0,717
79,0
623
0,719
80,0
625
0,722
81,0
628
0,724
82,0
630
0,727
83,0
632
0,729
84,0
635
0,732
85,0
637
0,734
86,0
639
0,737
87,0
642
0,739
88,0
644
0,742
89,0
647
0,744
90,0
649
0,747
91,0
651
0,749
92,0
654
0,752
93,0
656
0,755
94,0
659
0,757
95,0
661
0,760
96,0
664
0,762
97,0
666
0,765
98,0
668
0,767
99,0
671
0,770
100,0
673
0,773
101,0
676
0,775
102,0
678
0,778
103,0
681
0,780
104,0
683
0,783
105,0
686
0,786
106,0
688
0,788
107,0
691
0,791
108,0
693
0,793
109,0
696
0,796
110,0
698
0,799
111,0
701
0,801
112,0
703
0,804
113,0
706
0,807
114,0
708
0,809
115,0
711
0,812
116,0
713
0,815
117,0
716
0,817
118,0
718
0,820
119,0
721
0,823
120,0
724
0,825
