EN
Position your child and ensure that your KIDDY child restrain5 system is appro-
priately adjusted for your child's size (point 4).
In order to secure your child with the 3[point vehicle seat belt, proceed as follows:
Pull the vehicle seat belt out and place the lap belt under the two armrests (D)
of the seat (I) (Fig. 25). Ensure that the lap belt is in the lowest possible position.
Now close the belt latch. Check whether the belt latch has engaged correctly
(Fig. 25).
Tighten the lap belt and place the diagonal belt under the arm rest (D) on the
belt latch side (Fig. 26).
The diagonal belt must now be threaded into the diagonal belt guide (B). To do
this, open the hook (U) and place the belt in the diagonal belt guide (B). Please
ensure that the belt does not twist and that it can move through the belt guide
(Fig. 27).
Please ensure that the belt latch opposite the diagonal belt
!
guide (B) is used (Fig. 28).
The belts may not be twisted and must run closely along you child's body.
Ensure the correct position of the vehicle belt latch.
Then tighten the belt system (Fig. 28).
Check the belt run regularly during longer trips.

8 Opening the diagonal belt guide

To remove the diagonal belt from the diagonal belt guide (B), open the hook (U)
and pull the belt forwards out of the diagonal belt guide (B) (Fig. 29).
30
