Other interfering sources can be caused by switching
operations, electrical motors or defective electrical
devices.
The range of transmission within buildings
can greatly deviate from open air distances.
Besides the transmitting power and the reception
characteristics of the receiver, environmental
influences such as humidity in the vicinity and local
structures also play an important role.
Hereby eQ-3 AG, declares that this device conforms
with the essential requirements and other relevant
regulations of Directive 1999/5/EC.
The full declaration of conformity is provided under
www.HomeMatic.com.
6

Installation

The actuators for ceiling void mount installations are
suitable for invisible mounting in suspended ceilings
for example. Fastening tabs are provided on the
device to make fastening comfortable with screws.
28
The installation of the described actuators is shown in
the following connection diagrams. Remove the cover
over the terminal strip for making connections to the
device.
Connect the actuators to L and N for the supply. Run
the switched/dimmed channel circuit to the consumer.
A separate N-terminal is provided on the
dimmer for connecting to the consumer.
