Advanced Programming Options
The Acrobat HD Ultra Mini has advanced capabilities for modifying the programming of the
included remote control (when using multiple units) as well as changing the default
language used within the setup menus. These settings are completely optional and should
not be changed under normal circumstances. The information listed on the following pages
are for technical reference purposes only. Please see your Enhanced Vision representative
or call our toll-free technical support should it be necessary for you to modify these
settings.
Remote Codes
By default, a single remote control (and
corresponding remote control code) is
factory programmed and used for all Acrobat
camera functions. While acceptable for most
single-use applications, when 2 or more
Acrobats are used within close proximity to
each other (lab setting), exclusive remote
control over each unit may be desired.
Therefore, it is possible to modify the
sending/receiving codes of the remote
control and Acrobat head for exclusive use,
if desired. Up to 15 unique codes can be
assigned. For proper communication, both
the Remote control (transmit) and camera
head (receive) must be set to matching ID
codes. Please refer to the chart on the right
for more information.
Language Select
The default language used for the on-screen-display (OSD) may be changed by accessing
the Advanced Programming Features menu on the Acrobat. This is accomplished using a
special key combination sequence (4321), accessed by pressing the [+] and [MODE]
buttons on the Acrobat camera head. Language selection can be adjusted within the
second menu level. Please refer to the chart on the following page for detailed reference.
32
Remote Control (Transmit) Code Change:
• #28 (default/factory reset):
Push MODE and FIND for 3 secs.
• #15: Push MODE and LLM- for 3 secs.
• #24: Push MODE and ULM- for 3 secs.
• #25: Push MODE and LLM+ for 3 secs.
• #27: Push MODE and ULM+ for 3 secs.
• #07: Push + and FIND for 3 secs.
• #11: Push + and LLM- for 3 secs.
• #14: Push + and ULM- for 3 secs.
• #23: Push + and LLM+ for 3 secs.
• #31: Push + and ULM+ for 3 secs.
• #08: Push - and FIND for 3 secs.
• #09: Push - and LLM- for 3 secs.
• #10: Push - and ULM- for 3 secs.
• #12: Push - and LLM+ for 3 secs.
• #13: Push - and ULM+ for 3 secs.
Advance Programming
