janitza UMG 512-PRO Modbus-Adressenliste Und Formelsammlung Seite 43

Adresse Format RD/WR Bezeichnung
6568 float RD/WR _WH_Z_NT[4]
6570 float RD/WR _WH_Z_NT[5]
6572 float RD/WR _IQH[0]
6574 float RD/WR _IQH[1]
6576 float RD/WR _IQH[2]
6578 float RD/WR _IQH[3]
6580 float RD/WR _IQH[4]
6582 float RD/WR _IQH[5]
6584 float RD/WR _CQH[0]
6586 float RD/WR _CQH[1]
6588 float RD/WR _CQH[2]
6590 float RD/WR _CQH[3]
6592 float RD/WR _CQH[4]
6594 float RD/WR _CQH[5]
6596 float RD/WR _IQH_HT[0]
6598 float RD/WR _IQH_HT[1]
6600 float RD/WR _IQH_HT[2]
6602 float RD/WR _IQH_HT[3]
6604 float RD/WR _IQH_HT[4]
6606 float RD/WR _IQH_HT[5]
6608 float RD/WR _IQH_NT[0]
6610 float RD/WR _IQH_NT[1]
6612 float RD/WR _IQH_NT[2]
6614 float RD/WR _IQH_NT[3]
6616 float RD/WR _IQH_NT[4]
6618 float RD/WR _IQH_NT[5]
6620 float RD/WR _S0_CNT[0]
6622 float RD/WR _S0_CNT[1]
6624 float RD/WR _TIME_WH
6626 float RD/WR _TIME_QH
6654 short RD/WR _DEL_WH
6655 short RD/WR _DEL_QH
11760 float RD/WR _WH_V_T3[0]
11762 float RD/WR _WH_V_T3[1]
11764 float RD/WR _WH_V_T3[2]
11766 float RD/WR _WH_V_T3[3]
11768 float RD/WR _WH_V_T3[4]
11770 float RD/WR _WH_V_T3[5]
11772 float RD/WR _WH_V_T4[0]
11774 float RD/WR _WH_V_T4[1]
11776 float RD/WR _WH_V_T4[2]
11778 float RD/WR _WH_V_T4[3]
11780 float RD/WR _WH_V_T4[4]
11782 float RD/WR _WH_V_T4[5]
11784 float RD/WR _WH_Z_T3[0]
11786 float RD/WR _WH_Z_T3[1]
11788 float RD/WR _WH_Z_T3[2]
11790 float RD/WR _WH_Z_T3[3]
11792 float RD/WR _WH_Z_T3[4]
11794 float RD/WR _WH_Z_T3[5]
11796 float RD/WR _WH_Z_T4[0]
11798 float RD/WR _WH_Z_T4[1]
11800 float RD/WR _WH_Z_T4[2]
11802 float RD/WR _WH_Z_T4[3]
11804 float RD/WR _WH_Z_T4[4]
11806 float RD/WR _WH_Z_T4[5]
Einheit Bemerkung
Wh Real energy L1..L3, delivered, rate 2
Wh Real energy L1..L4, delivered, rate 2
varh Reactive energy L1, inductive
varh Reactive energy L2, inductive
varh Reactive energy L3, inductive
varh Reactive energy L4, inductive
varh Reactive energy L1..L3, inductive
varh Reactive energy L1..L4, inductive
varh Reactive energy L1, capacitive
varh Reactive energy L2, capacitive
varh Reactive energy L3, capacitive
varh Reactive energy L4, capacitive
varh Reactive energy L1..L3, capacitive
varh Reactive energy L1..L4, capacitive
varh Reactive energy L1, inductive, rate 1
varh Reactive energy L2, inductive, rate 1
varh Reactive energy L3, inductive, rate 1
varh Reactive energy L4, inductive, rate 1
varh Reactive energy L1..L3, inductive, rate 1
varh Reactive energy L1..L4, inductive, rate 1
varh Reactive energy L1, inductive, rate 2
varh Reactive energy L2, inductive, rate 2
varh Reactive energy L3, inductive, rate 2
varh Reactive energy L4, inductive, rate 2
varh Reactive energy L1..L3, inductive, rate 2
varh Reactive energy L1..L4, inductive, rate 2
Energy meter (counter, not scaled), impulse input 1
Energy meter (counter, not scaled), impulse input 2
s Runtime of real and apparent energy meas.
s Runtime of real and reactive energy meas.
1=delete all real energy counters
1=delete all reactive energy counters
Wh Real energy L1, consumed, rate 3
Wh Real energy L2, consumed, rate 3
Wh Real energy L3, consumed, rate 3
Wh Real energy L4, consumed, rate 3
Wh Real energy L1..L3, consumed, rate 3
Wh Real energy L1..L4, consumed, rate 3
Wh Real energy L1, consumed, rate 4
Wh Real energy L2, consumed, rate 4
Wh Real energy L3, consumed, rate 4
Wh Real energy L4, consumed, rate 4
Wh Real energy L1..L3, consumed, rate 4
Wh Real energy L1..L4, consumed, rate 4
Wh Real energy L1, delivered, rate 3
Wh Real energy L2, delivered, rate 3
Wh Real energy L3, delivered, rate 3
Wh Real energy L4, delivered, rate 3
Wh Real energy L1..L3, delivered, rate 3
Wh Real energy L1..L4, delivered, rate 3
Wh Real energy L1, delivered, rate 4
Wh Real energy L2, delivered, rate 4
Wh Real energy L3, delivered, rate 4
Wh Real energy L4, delivered, rate 4
Wh Real energy L1..L3, delivered, rate 4
Wh Real energy L1..L4, delivered, rate 4
Modbus-Adressenliste
UMG 512
43
