janitza UMG 512-PRO Modbus-Adressenliste Und Formelsammlung Seite 27

Adresse Format RD/WR Bezeichnung
5132 short RD/WR _ULL_NEG_PEAK_AVG_T[2]
5133 short RD/WR _ULL_POS_PEAK_AVG_T[0]
5134 short RD/WR _ULL_POS_PEAK_AVG_T[1]
5135 short RD/WR _ULL_POS_PEAK_AVG_T[2]
5136 short RD/WR _ULL_PEAK_PEAK_AVG_T[0]
5137 short RD/WR _ULL_PEAK_PEAK_AVG_T[1]
5138 short RD/WR _ULL_PEAK_PEAK_AVG_T[2]
5139 short RD/WR _U_STERN_AVG_T
5140 short RD/WR _U_SYM_AVG_T
5141 short RD/WR _FREQ_AVG_T
5142 short RD/WR _NORM_FREQ_AVG_T
5143 short RD/WR _PLN_AVG_T[0]
5144 short RD/WR _PLN_AVG_T[1]
5145 short RD/WR _PLN_AVG_T[2]
5146 short RD/WR _PLN_AVG_T[3]
5147 short RD/WR _P_SUM_AVG_T
5148 short RD/WR _Q_SUM_AVG_T
5149 short RD/WR _QLN_AVG_T[0]
5150 short RD/WR _QLN_AVG_T[1]
5151 short RD/WR _QLN_AVG_T[2]
5152 short RD/WR _QLN_AVG_T[3]
5153 short RD/WR _P_SUM3_AVG_T
5154 short RD/WR _Q_SUM3_AVG_T
5155 short RD/WR _ILN_AVG_T[0]
5156 short RD/WR _ILN_AVG_T[1]
5157 short RD/WR _ILN_AVG_T[2]
5158 short RD/WR _ILN_AVG_T[3]
5159 short RD/WR _SLN_AVG_T[0]
5160 short RD/WR _SLN_AVG_T[1]
5161 short RD/WR _SLN_AVG_T[2]
5162 short RD/WR _SLN_AVG_T[3]
5163 short RD/WR _I_SUM3_AVG_T
5164 short RD/WR _I_SUM_AVG_T
5165 short RD/WR _S_SUM3_AVG_T
5166 short RD/WR _S_SUM_AVG_T
5167 short RD/WR _THD_IL_AVG_T[0]
5168 short RD/WR _THD_IL_AVG_T[1]
5169 short RD/WR _THD_IL_AVG_T[2]
5170 short RD/WR _THD_IL_AVG_T[3]
5171 short RD/WR _ZHD_IL_AVG_T[0]
5172 short RD/WR _ZHD_IL_AVG_T[1]
5173 short RD/WR _ZHD_IL_AVG_T[2]
5174 short RD/WR _ZHD_IL_AVG_T[3]
5175 short RD/WR _ILN_CF_AVG_T[0]
5176 short RD/WR _ILN_CF_AVG_T[1]
5177 short RD/WR _ILN_CF_AVG_T[2]
5178 short RD/WR _ILN_CF_AVG_T[3]
5179 short RD/WR _IN_AVG_T
5180 short RD/WR _IM_AVG_T
5181 short RD/WR _IG_AVG_T
5182 short RD/WR _I_SYM_AVG_T
5183 short RD/WR _ILN_OVER_AVG_T[0]
5184 short RD/WR _ILN_OVER_AVG_T[1]
5185 short RD/WR _ILN_OVER_AVG_T[2]
5186 short RD/WR _ILN_OVER_AVG_T[3]
5187 short RD/WR _ILN_UNDER_AVG_T[0]
5188 short RD/WR _ILN_UNDER_AVG_T[1]
5189 short RD/WR _ILN_UNDER_AVG_T[2]
5190 short RD/WR _ILN_UNDER_AVG_T[3]
5191 short RD/WR _ILN_NEG_PEAK_AVG_T[0]
5192 short RD/WR _ILN_NEG_PEAK_AVG_T[1]
Einheit Bemerkung
n Averaging time, peak value negative, U L3-L1
n Averaging time, peak value positive, U L1-L2
n Averaging time, peak value positive, U L2-L3
n Averaging time, peak value positive, U L3-L1
n Averaging time, peak-peak value, U L1-L2
n Averaging time, peak-peak value, U L2-L3
n Averaging time, peak-peak value, U L3-L1
n Averaging time, unsymmetrical voltage
n Averaging time, measured frequency
n Averaging time, nominal frequency
n Averaging time, real power L1
n Averaging time, real power L2
n Averaging time, real power L3
n Averaging time, real power L4
n Averaging time, sum P = P1 + P2 + P3 + P4
n Averaging time, mains frequency reactive power
Sum Q = Q1 + Q2 + Q3 + Q4
n Averaging time, reactive power L1
n Averaging time, reactive power L2
n Averaging time, reactive power L3
n Averaging time, reactive power L4
n Averaging time, Sum P = P1 + P2 + P3
n Averaging time, mains frequency reactive power
Sum Q = Q1 + Q2 + Q3
n Averaging time, apparent current, L1
n Averaging time, apparent current, L2
n Averaging time, apparent current, L3
n Averaging time, apparent current, L4
n Averaging time, apparent power L1
n Averaging time, apparent power L2
n Averaging time, apparent power L3
n Averaging time, apparent power L4
n Averaging time, vector sum; IN = I1 + I2 + I3
n Averaging time, vector sum; I1 + I2 + I3 + I4
n Averaging time, sum; S = S1 + S2 + S3
n Averaging time, sum; S = S1 + S2 + S3 + S4
n Averaging time, harmonic, THD, I L1
n Averaging time, harmonic, THD, I L2
n Averaging time, harmonic, THD, I L3
n Averaging time, harmonic, THD, I L4
n Averaging time, interharmonics, ZHD, I, L1
n Averaging time, interharmonics, ZHD, I, L2
n Averaging time, interharmonics, ZHD, I, L3
n Averaging time, interharmonics, ZHD, I, L4
n Averaging time, crest factor, I L1
n Averaging time, crest factor, I L2
n Averaging time, crest factor, I L3
n Averaging time, crest factor, I L4
n Averaging time, zero sequence, current
n Averaging time, positive sequence, current
n Averaging time, negative sequence, current
n Averaging time, unsymmetrical current
n Averaging time, over difference, I L1
n Averaging time, over difference, I L2
n Averaging time, over difference, I L3
n Averaging time, over difference, I L4
n Averaging time, under difference, I L1
n Averaging time, under difference, I L2
n Averaging time, under difference, I L3
n Averaging time, under difference, I L4
n Averaging time, peak value negative, I L1
n Averaging time, peak value negative, I L2
Modbus-Adressenliste
UMG 512
27
