janitza UMG 512-PRO Modbus-Adressenliste Und Formelsammlung Seite 25

Adresse Format RD/WR Bezeichnung
4963 float RD/WR _ILN_UNDER_MAX[2]
4965 float RD/WR _ILN_UNDER_MAX[3]
4967 float RD/WR _ILN_NEG_PEAK_MAX[0]
4969 float RD/WR _ILN_NEG_PEAK_MAX[1]
4971 float RD/WR _ILN_NEG_PEAK_MAX[2]
4973 float RD/WR _ILN_NEG_PEAK_MAX[3]
4975 float RD/WR _ILN_POS_PEAK_MAX[0]
4977 float RD/WR _ILN_POS_PEAK_MAX[1]
4979 float RD/WR _ILN_POS_PEAK_MAX[2]
4981 float RD/WR _ILN_POS_PEAK_MAX[3]
4983 float RD/WR _ILN_PEAK_PEAK_MAX[0]
4985 float RD/WR _ILN_PEAK_PEAK_MAX[1]
4987 float RD/WR _ILN_PEAK_PEAK_MAX[2]
4989 float RD/WR _ILN_PEAK_PEAK_MAX[3]
4991 float RD/WR _FLI_PF5_MAX[0]
4993 float RD/WR _FLI_PF5_MAX[1]
4995 float RD/WR _FLI_PF5_MAX[2]
4997 float RD/WR _FLI_PF5_MAX[3]
4999 float RD/WR _FLI_ST_MAX[0]
5001 float RD/WR _FLI_ST_MAX[1]
5003 float RD/WR _FLI_ST_MAX[2]
5005 float RD/WR _FLI_ST_MAX[3]
5007 float RD/WR _FLI_LT_MAX[0]
5009 float RD/WR _FLI_LT_MAX[1]
5011 float RD/WR _FLI_LT_MAX[2]
5013 float RD/WR _FLI_LT_MAX[3]
5015 float RD/WR _ILN_RC_MAX[0]
5017 float RD/WR _ILN_RC_MAX[1]
5019 float RD/WR _ILN_RC_MAX[2]
5021 float RD/WR _ILN_RC_MAX[3]
5023 float RD/WR _ULL_RC_MAX[0]
5025 float RD/WR _ULL_RC_MAX[1]
5027 float RD/WR _ULL_RC_MAX[2]
5039 float RD/WR _PFLN_MAX[0]
5041 float RD/WR _PFLN_MAX[1]
5043 float RD/WR _PFLN_MAX[2]
5045 float RD/WR _PFLN_MAX[3]
5047 float RD/WR _DLN_MAX[0]
5049 float RD/WR _DLN_MAX[1]
5051 float RD/WR _DLN_MAX[2]
5053 float RD/WR _DLN_MAX[3]
5055 float RD/WR _KFACT_MAX[0]
5057 float RD/WR _KFACT_MAX[1]
5059 float RD/WR _KFACT_MAX[2]
5061 float RD/WR _KFACT_MAX[3]
5063 float RD/WR _S0_POWER_MAX[0]
5065 float RD/WR _S0_POWER_MAX[1]
5067 float RD/WR _TEMPERATUR_MAX
Einheit Bemerkung
% Max. value, under difference, I L3
% Max. value, under difference, I L4
A Max. value, peak value negative, I L1
A Max. value, peak value negative, I L2
A Max. value, peak value negative, I L3
A Max. value, peak value negative, I L4
A Max. value, peak value positive, I L1
A Max. value, peak value positive, I L2
A Max. value, peak value positive, I L3
A Max. value, peak value positive, I L4
A Max. value, peak-peak value, I L1
A Max. value, peak-peak value, I L2
A Max. value, peak-peak value, I L3
A Max. value, peak-peak value, I L4
Max. value, current flicker Pf5, L1-N
Max. value, current flicker Pf5, L2-N
Max. value, current flicker Pf5, L3-N
Max. value, current flicker Pf5, L4-N
A Max. value, ripple control signal, I L1
A Max. value, ripple control signal, I L2
A Max. value, ripple control signal, I L3
A Max. value, ripple control signal, I L4
V Max. value, ripple control signal, U L1-L2
V Max. value, ripple control signal, U L2-L3
V Max. value, ripple control signal, U L3-L1
% Max. value, power factor; L1
% Max. value, power factor; L2
% Max. value, power factor; L3
% Max. value, power factor; L4
var Max. value, distortion power factor; L1
var Max. value, distortion power factor; L2
var Max. value, distortion power factor; L3
var Max. value, distortion power factor; L4
% Max. value, K-Factor, L1
% Max. value, K-Factor, L2
% Max. value, K-Factor, L3
% Max. value, K-Factor, L4
W Max. value, Input 1, measured value
W Max. value, Input 2, measured value
°C Max. value, internal temperature
