Adresse Format RD/WR Bezeichnung
6234 uint RD/WR _ULL_UNDER_AVG_MAX_T[1]
6236 uint RD/WR _ULL_UNDER_AVG_MAX_T[2]
6238 uint RD/WR _ULL_NEG_PEAK_AVG_MAX_T[0] s
6240 uint RD/WR _ULL_NEG_PEAK_AVG_MAX_T[1] s
6242 uint RD/WR _ULL_NEG_PEAK_AVG_MAX_T[2] s
6244 uint RD/WR _ULL_POS_PEAK_AVG_MAX_T[0] s
6246 uint RD/WR _ULL_POS_PEAK_AVG_MAX_T[1] s
6248 uint RD/WR _ULL_POS_PEAK_AVG_MAX_T[2] s
6250 uint RD/WR _ULL_PEAK_PEAK_AVG_MAX_T[0] s
6252 uint RD/WR _ULL_PEAK_PEAK_AVG_MAX_T[1] s
6254 uint RD/WR _ULL_PEAK_PEAK_AVG_MAX_T[2] s
6256 uint RD/WR _U_STERN_AVG_MAX_T
6258 uint RD/WR _U_SYM_AVG_MAX_T
6260 uint RD/WR _FREQ_AVG_MAX_T
6262 uint RD/WR _NORM_FREQ_AVG_MAX_T
6264 uint RD/WR _PLN_AVG_MAX_T[0]
6266 uint RD/WR _PLN_AVG_MAX_T[1]
6268 uint RD/WR _PLN_AVG_MAX_T[2]
6270 uint RD/WR _PLN_AVG_MAX_T[3]
6272 uint RD/WR _P_SUM_AVG_MAX_T
6274 uint RD/WR _Q_SUM_AVG_MAX_T
6276 uint RD/WR _QLN_AVG_MAX_T[0]
6278 uint RD/WR _QLN_AVG_MAX_T[1]
6280 uint RD/WR _QLN_AVG_MAX_T[2]
6282 uint RD/WR _QLN_AVG_MAX_T[3]
6284 uint RD/WR _P_SUM3_AVG_MAX_T
6286 uint RD/WR _Q_SUM3_AVG_MAX_T
6288 uint RD/WR _ILN_AVG_MAX_T[0]
6290 uint RD/WR _ILN_AVG_MAX_T[1]
6292 uint RD/WR _ILN_AVG_MAX_T[2]
6294 uint RD/WR _ILN_AVG_MAX_T[3]
6296 uint RD/WR _SLN_AVG_MAX_T[0]
6298 uint RD/WR _SLN_AVG_MAX_T[1]
6300 uint RD/WR _SLN_AVG_MAX_T[2]
6302 uint RD/WR _SLN_AVG_MAX_T[3]
6304 uint RD/WR _I_SUM3_AVG_MAX_T
6306 uint RD/WR _I_SUM_AVG_MAX_T
6308 uint RD/WR _S_SUM3_AVG_MAX_T
6310 uint RD/WR _S_SUM_AVG_MAX_T
6312 uint RD/WR _THD_IL_AVG_MAX_T[0]
6314 uint RD/WR _THD_IL_AVG_MAX_T[1]
6316 uint RD/WR _THD_IL_AVG_MAX_T[2]
6318 uint RD/WR _THD_IL_AVG_MAX_T[3]
6320 uint RD/WR _ZHD_IL_AVG_MAX_T[0]
6322 uint RD/WR _ZHD_IL_AVG_MAX_T[1]
6324 uint RD/WR _ZHD_IL_AVG_MAX_T[2]
6326 uint RD/WR _ZHD_IL_AVG_MAX_T[3]
6328 uint RD/WR _ILN_CF_AVG_MAX_T[0]
6330 uint RD/WR _ILN_CF_AVG_MAX_T[1]
6332 uint RD/WR _ILN_CF_AVG_MAX_T[2]
6334 uint RD/WR _ILN_CF_AVG_MAX_T[3]
6336 uint RD/WR _IN_AVG_MAX_T
6338 uint RD/WR _IM_AVG_MAX_T
6340 uint RD/WR _IG_AVG_MAX_T
6342 uint RD/WR _I_SYM_AVG_MAX_T
6344 uint RD/WR _ILN_OVER_AVG_MAX_T[0]
6346 uint RD/WR _ILN_OVER_AVG_MAX_T[1]
6348 uint RD/WR _ILN_OVER_AVG_MAX_T[2]
6350 uint RD/WR _ILN_OVER_AVG_MAX_T[3]
6352 uint RD/WR _ILN_UNDER_AVG_MAX_T[0]
6354 uint RD/WR _ILN_UNDER_AVG_MAX_T[1]
6356 uint RD/WR _ILN_UNDER_AVG_MAX_T[2]
6358 uint RD/WR _ILN_UNDER_AVG_MAX_T[3]
Einheit Bemerkung
s Time of max. val. of mean val., under difference, U L2-L3
s Time of max. val. of mean val., under difference, U L3-L1
Time of max. val. of mean val., peak value neg. U L1-L2
Time of max. val. of mean val., peak value neg., U L2-L3
Time of max. val. of mean val., peak value neg, U L3-L1
Time of max. val. of mean val., peak value pos., U L1-L2
Time of max. val. of mean val., peak value pos., U L2-L3
Time of max. val. of mean val., peak value pos., U L3-L1
Time of max. val. of mean val., peak-peak value, U L1-L2
Time of max. val. of mean val., peak-peak value, U L2-L3
Time of max. val. of mean val., peak-peak value, U L3-L1
s
s Time of max. val. of mean val., unsymmetrical voltage
s Time of max. val. of mean val., measured frequency
s Time of max. val. of mean val., nominal frequency
s Time of max. val. of mean val., real power L1
s Time of max. val. of mean val., real power L2
s Time of max. val. of mean val., real power L3
s Time of max. val. of mean val., real power L4
s Time of max. val. of mean val., sum P = P1+P2+P3+P4
s Time of max. val. of mean val., sum Q = Q1+Q2+Q3+Q4
s Time of max. val. of mean val., reactive power L1
s Time of max. val. of mean val., reactive power L2
s Time of max. val. of mean val., reactive power L3
s Time of max. val. of mean val., reactive power L4
s Time of max. val. of mean val., sum P = P1+P2+P3
s Time of max. val. of mean val., sum Q = Q1+Q2+Q3+Q4
s Time of max. val. of mean val., apparent current, L1
s Time of max. val. of mean val., apparent current, L2
s Time of max. val. of mean val., apparent current, L3
s Time of max. val. of mean val., apparent current, L4
s Time of max. val. of mean val., apparent power L1
s Time of max. val. of mean val., apparent power L2
s Time of max. val. of mean val., apparent power L3
s Time of max. val. of mean val., apparent power L4
s Time of max. val. of mean val., vector sum; IN = I1+I2+I3
s Time of max. val. of mean val., vector sum; I1+I2+I3+I4
s Time of max. val. of mean val., sum S = S1+S2+S3
s Time of max. val. of mean val., sum S = S1+S2+S3+S4
s Time of max. val. of mean val., harmonic, THD, I L1
s Time of max. val. of mean val., harmonic, THD, I L2
s Time of max. val. of mean val., harmonic, THD, I L3
s Time of max. val. of mean val., harmonic, THD, I L4
s Time of max. val. of mean val., interharmonic, ZHD, I L1
s Time of max. val. of mean val., interharmonic, ZHD, I L2
s Time of max. val. of mean val., interharmonic, ZHD, I L3
s Time of max. val. of mean val., interharmonic, ZHD, I L4
s Time of max. val. of mean val., crest factor, I L1
s Time of max. val. of mean val., crest factor, I L2
s Time of max. val. of mean val., crest factor, I L3
s Time of max. val. of mean val., crest factor, I L4
s Time of max. val. of mean val., zero sequence, current
s Time of max. val. of mean val., positive sequence, current
s Time of max. val. of mean val., negative sequence, current
s Time of max. val. of mean val., unsymmetrical; current
s Time of max. val. of mean val., over difference, I L1
s Time of max. val. of mean val., over difference, I L2
s Time of max. val. of mean val., over difference, I L3
s Time of max. val. of mean val., over difference, I L4
s Time of max. val. of mean val., under difference, I L1
s Time of max. val. of mean val., under difference, I L2
s Time of max. val. of mean val., under difference, I L3
s Time of max. val. of mean val., under difference, I L4
