Modbus-Adressenliste
Adresse Format RD/WR Bezeichnung
4841 float RD/WR _ULL_UNDER_MAX[1]
4843 float RD/WR _ULL_UNDER_MAX[2]
4845 float RD/WR _ULL_NEG_PEAK_MAX[0]
4847 float RD/WR _ULL_NEG_PEAK_MAX[1]
4849 float RD/WR _ULL_NEG_PEAK_MAX[2]
4851 float RD/WR _ULL_POS_PEAK_MAX[0]
4853 float RD/WR _ULL_POS_PEAK_MAX[1]
4855 float RD/WR _ULL_POS_PEAK_MAX[2]
4857 float RD/WR _ULL_PEAK_PEAK_MAX[0]
4859 float RD/WR _ULL_PEAK_PEAK_MAX[1]
4861 float RD/WR _ULL_PEAK_PEAK_MAX[2]
4863 float RD/WR _U_STERN_MAX
4865 float RD/WR _U_SYM_MAX
4867 float RD/WR _FREQ_MAX
4869 float RD/WR _NORM_FREQ_MAX
4871 float RD/WR _PLN_MAX[0]
4873 float RD/WR _PLN_MAX[1]
4875 float RD/WR _PLN_MAX[2]
4877 float RD/WR _PLN_MAX[3]
4879 float RD/WR _P_SUM_MAX
4881 float RD/WR _Q_SUM_MAX
4883 float RD/WR _QLN_MAX[0]
4885 float RD/WR _QLN_MAX[1]
4887 float RD/WR _QLN_MAX[2]
4889 float RD/WR _QLN_MAX[3]
4891 float RD/WR _P_SUM3_MAX
4893 float RD/WR _Q_SUM3_MAX
4895 float RD/WR _ILN_MAX[0]
4897 float RD/WR _ILN_MAX[1]
4899 float RD/WR _ILN_MAX[2]
4901 float RD/WR _ILN_MAX[3]
4903 float RD/WR _SLN_MAX[0]
4905 float RD/WR _SLN_MAX[1]
4907 float RD/WR _SLN_MAX[2]
4909 float RD/WR _SLN_MAX[3]
4911 float RD/WR _I_SUM3_MAX
4913 float RD/WR _I_SUM_MAX
4915 float RD/WR _S_SUM3_MAX
4917 float RD/WR _S_SUM_MAX
4919 float RD/WR _THD_IL_MAX[0]
4921 float RD/WR _THD_IL_MAX[1]
4923 float RD/WR _THD_IL_MAX[2]
4925 float RD/WR _THD_IL_MAX[3]
4927 float RD/WR _ZHD_IL_MAX[0]
4929 float RD/WR _ZHD_IL_MAX[1]
4931 float RD/WR _ZHD_IL_MAX[2]
4933 float RD/WR _ZHD_IL_MAX[3]
4935 float RD/WR _ILN_CF_MAX[0]
4937 float RD/WR _ILN_CF_MAX[1]
4939 float RD/WR _ILN_CF_MAX[2]
4941 float RD/WR _ILN_CF_MAX[3]
4943 float RD/WR _IN_MAX
4945 float RD/WR _IM_MAX
4947 float RD/WR _IG_MAX
4949 float RD/WR _I_SYM_MAX
4951 float RD/WR _ILN_OVER_MAX[0]
4953 float RD/WR _ILN_OVER_MAX[1]
4955 float RD/WR _ILN_OVER_MAX[2]
4957 float RD/WR _ILN_OVER_MAX[3]
4959 float RD/WR _ILN_UNDER_MAX[0]
4961 float RD/WR _ILN_UNDER_MAX[1]
UMG 512
24
Einheit Bemerkung
% Max. value, under difference, U L2-L3 (61000-4-30)
% Max. value, under difference, U L3-L1 (61000-4-30)
V Max. value, peak value negative, U L1-L2
V Max. value, peak value negative, U L2-L3
V Max. value, peak value negative, U L3-L1
V Max. value, peak value positive, U L1-L2
V Max. value, peak value positive, U L2-L3
V Max. value, peak value positive, U L3-L1
V Max. value, peak-peak value, U L1-L2
V Max. value, peak-peak value, U L2-L3
V Max. value, peak-peak value, U L3-L1
V
% Max. value, unsymmetrical; voltage
Hz Max. value, measured frequency
Hz Max. value, nominal frequency
W Max. value, real power L1
W Max. value, real power L2
W Max. value, real power L3
W Max. value, real power L4
W Max. value, sum; P = P1 + P2 + P3 + P4
var Max. value, mains frequency reactive power
Sum; Q = Q1 + Q2 + Q3 + Q4
var Max. value, reactive power L1 (fundamental comp.)
var Max. value, reactive power L2 (fundamental comp.)
var Max. value, reactive power L3 (fundamental comp.)
var Max. value, reactive power L4 (fundamental comp.)
W Max. value, Sum; P = P1 + P2 + P3
var Max. value, mains frequency reactive power
Sum; Q = Q1 + Q2 + Q3
A Max. value, apparent current, L1
A Max. value, apparent current, L2
A Max. value, apparent current, L3
A Max. value, apparent current, L4
VA Max. value, apparent power L1
VA Max. value, apparent power L2
VA Max. value, apparent power L3
VA Max. value, apparent power L4
A Max. value, vector sum; IN = I1 + I2 + I3
A Max. value, vector sum; I1 + I2 + I3 + I4
VA Max. value, sum; S = S1 + S2 + S3
VA Max. value, sum; S = S1 + S2 + S3 + S4
% Max. value, harmonic, THD, I L1
% Max. value, harmonic, THD, I L2
% Max. value, harmonic, THD, I L3
% Max. value, harmonic, THD, I L4
% Max. value, interharmonics, ZHD, I, L1
% Max. value, interharmonics, ZHD, I, L2
% Max. value, interharmonics, ZHD, I, L3
% Max. value, interharmonics, ZHD, I, L4
Max. value, crest factor, I L1
Max. value, crest factor, I L2
Max. value, crest factor, I L3
Max. value, crest factor, I L4
A Max. value, zero sequence, current
A Max. value, positive sequence, current
A Max. value, negative sequence, current
% Max. value, unsymmetrical; current
% Max. value, over difference, I L1
% Max. value, over difference, I L2
% Max. value, over difference, I L3
% Max. value, over difference, I L4
% Max. value, under difference, I L1
% Max. value, under difference, I L2
