janitza UMG 512-PRO Modbus-Adressenliste Und Formelsammlung Seite 19

Adresse Format RD/WR Bezeichnung
4337 float RD/WR _ULL_PEAK_PEAK_AVG[0]
4339 float RD/WR _ULL_PEAK_PEAK_AVG[1]
4341 float RD/WR _ULL_PEAK_PEAK_AVG[2]
4343 float RD/WR _U_STERN_AVG
4345 float RD/WR _U_SYM_AVG
4347 float RD/WR _FREQ_AVG
4349 float RD/WR _NORM_FREQ_AVG
4351 float RD/WR _PLN_AVG[0]
4353 float RD/WR _PLN_AVG[1]
4355 float RD/WR _PLN_AVG[2]
4357 float RD/WR _PLN_AVG[3]
4359 float RD/WR _P_SUM_AVG
4361 float RD/WR _Q_SUM_AVG
4363 float RD/WR _QLN_AVG[0]
4365 float RD/WR _QLN_AVG[1]
4367 float RD/WR _QLN_AVG[2]
4369 float RD/WR _QLN_AVG[3]
4371 float RD/WR _P_SUM3_AVG
4373 float RD/WR _Q_SUM3_AVG
4375 float RD/WR _ILN_AVG[0]
4377 float RD/WR _ILN_AVG[1]
4379 float RD/WR _ILN_AVG[2]
4381 float RD/WR _ILN_AVG[3]
4383 float RD/WR _SLN_AVG[0]
4385 float RD/WR _SLN_AVG[1]
4387 float RD/WR _SLN_AVG[2]
4389 float RD/WR _SLN_AVG[3]
4391 float RD/WR _I_SUM3_AVG
4393 float RD/WR _I_SUM_AVG
4395 float RD/WR _S_SUM3_AVG
4397 float RD/WR _S_SUM_AVG
4399 float RD/WR _THD_IL_AVG[0]
4401 float RD/WR _THD_IL_AVG[1]
4403 float RD/WR _THD_IL_AVG[2]
4405 float RD/WR _THD_IL_AVG[3]
4407 float RD/WR _ZHD_IL_AVG[0]
4409 float RD/WR _ZHD_IL_AVG[1]
4411 float RD/WR _ZHD_IL_AVG[2]
4413 float RD/WR _ZHD_IL_AVG[3]
4415 float RD/WR _ILN_CF_AVG[0]
4417 float RD/WR _ILN_CF_AVG[1]
4419 float RD/WR _ILN_CF_AVG[2]
4421 float RD/WR _ILN_CF_AVG[3]
4423 float RD/WR _IN_AVG
4425 float RD/WR _IM_AVG
4427 float RD/WR _IG_AVG
4429 float RD/WR _I_SYM_AVG
4431 float RD/WR _ILN_OVER_AVG[0]
4433 float RD/WR _ILN_OVER_AVG[1]
4435 float RD/WR _ILN_OVER_AVG[2]
4437 float RD/WR _ILN_OVER_AVG[3]
4439 float RD/WR _ILN_UNDER_AVG[0]
4441 float RD/WR _ILN_UNDER_AVG[1]
4443 float RD/WR _ILN_UNDER_AVG[2]
4445 float RD/WR _ILN_UNDER_AVG[3]
4447 float RD/WR _ILN_NEG_PEAK_AVG[0]
4449 float RD/WR _ILN_NEG_PEAK_AVG[1]
4451 float RD/WR _ILN_NEG_PEAK_AVG[2]
4453 float RD/WR _ILN_NEG_PEAK_AVG[3]
4455 float RD/WR _ILN_POS_PEAK_AVG[0]
4457 float RD/WR _ILN_POS_PEAK_AVG[1]
Einheit Bemerkung
V Mean value, peak-peak value, U L1-L2
V Mean value, peak-peak value, U L2-L3
V Mean value, peak-peak value, U L3-L1
V
% Mean value, unsymmetrical, voltage
Hz Mean value, measured frequency
Hz Mean value, nominal frequency
W Mean value, real power L1
W Mean value, real power L2
W Mean value, real power L3
W Mean value, real power L4
W Mean value, sum; P = P1 + P2 + P3 + P4
var Mean value, mains frequency reactive power
Sum; Q = Q1 + Q2 + Q3 + Q4
var Mean value, reactive power L1 (fundamental comp.)
var Mean value, reactive power L2 (fundamental comp.)
var Mean value, reactive power L3 (fundamental comp.)
var Mean value, reactive power L4 (fundamental comp.)
W Mean value, Sum; P = P1 + P2 + P3
var Mean value, mains frequency reactive power
Sum; Q = Q1 + Q2 + Q3
A Mean value, apparent current, L1
A Mean value, apparent current, L2
A Mean value, apparent current, L3
A Mean value, apparent current, L4
VA Mean value, apparent power L1
VA Mean value, apparent power L2
VA Mean value, apparent power L3
VA Mean value, apparent power L4
A Mean value, vector sum; IN = I1 + I2 + I3
A Mean value, vector sum; I1 + I2 + I3 + I4
VA Mean value, sum; S = S1 + S2 + S3
VA Mean value, sum; S = S1 + S2 + S3 + S4
% Mean value, harmonic, THD, I L1
% Mean value, harmonic, THD, I L2
% Mean value, harmonic, THD, I L3
% Mean value, harmonic, THD, I L4
% Mean value, interharmonics, ZHD, I, L1
% Mean value, interharmonics, ZHD, I, L2
% Mean value, interharmonics, ZHD, I, L3
% Mean value, interharmonics, ZHD, I, L4
Mean value, crest factor, I L1
Mean value, crest factor, I L2
Mean value, crest factor, I L3
Mean value, crest factor, I L4
A Mean value, zero sequence, current
A Mean value, positive sequence, current
A Mean value, negative sequence, current
% Mean value, unsymmetrical, current
% Mean value, over difference, I L1
% Mean value, over difference, I L2
% Mean value, over difference, I L3
% Mean value, over difference, I L4
% Mean value, under difference, I L1
% Mean value, under difference, I L2
% Mean value, under difference, I L3
% Mean value, under difference, I L4
A Mean value, peak value negative, I L1
A Mean value, peak value negative, I L2
A Mean value, peak value negative, I L3
A Mean value, peak value negative, I L4
A Mean value, peak value positive, I L1
A Mean value, peak value positive, I L2
Modbus-Adressenliste
UMG 512
19
