Technical Data

HxWxL
Weight
Inlet
Collection container
Hose length(Ø 50)
Flow Max
Negative Pressure, Max
Motor Power
Fine fi lter polyester
Degree of separation,
(EN 60335-2-69, Class M)
Sound level*/
* / Sound Pressure Level at 1.6 m height and 1 m according to DIN EN
ISO 3744 in free space at maximum airfl ow.

Description

Collected material is stored in a 40 liters container
which is easily removed from the unit in one simple
operation. The collected material is ergonomically
handled in this way for recycling or disposal. A
sightglass on the container provides for continous
monitoring during operation. The container has a
maximum capacity of 60 kg of material.
2018-04-05
2.2 kW
1470x660x1100 mm
ca 85 kg
X 50 mm
40 l
5-15 m
260 m /h
3
28 kPa
2.2 kW
1.8 m
2
99.9%
60 dB(A)
kPa
20
10
The DC 3800i is stable, tough and reliable and parti-
cularly well suited to source extraction and cleaning
in a large variety of applications; welding, grinding,
sanding and fl oor cleaning. With a very low sound
level, the DC 3800i is particularly well suited for use
in areas which are sensitive to noise.
The DC 3800i is powered by a 3 phase Dustcontrol
turbo pump.
5DC 3800i - 9
3 kW 60 Hz
1470x660x1100 mm
ca 85 kg
X50 mm
40 l
5-15 m
320 m /h
3
31 kPa
4 HP
1.8 m
2
99.9%
60 dB(A)
Vacuum producer capacity
DC 3800i 4 HP 60 Hz
DC 3800i
2.2 kW 50 Hz
100 200 300 400 m /h
3
Art Nr 94132-C
