Technical Data; Description - Dustcontrol Dc 5800A Originalbetriebsanleitung

Technical Data

HxWxL
Weight
Inlet
Collecting sack
Hose length (φ 50)
Flow, max
Neg. pressure, max
Power consumption
Fine fi lter
Degree of separation
(EN 60335-2-69-Class M) 99,9 %
Filter area, microfi lter
Degree of separation,
microfi lter (EN 1822-1)
(EN 60335-2-69, Class H) > 99.995 %
Sound level */
*/Sound level at 1.6 m height and 1 m distance according to
DIN EN ISO 3744 in free space and at maximum airfl ow.

Description

Th e DC 5800a is an electric powered vacuum extractor
for use with source extraction, cleaning and material
transportation applications in most types of industries.
Th e extraction system functions with negative pressure
(vacuum) that draws the air through suction casings,
nozzles, hose systems, separator and fi lter systems. Coarse
separation of dust occurs in the unit's cyclone which is a
When emptying the container, it is unclipped
and removed away from the machine. After
that has be done the sack can be taken out of
the container.
2011-07-07
50 Hz 60 Hz
1920x760x1000 mm
ca 170 kg ca 190 kg
φ 76 mm φ 76 mm
75 l 75 l
5-30 m 5-30 m
470 m3/h 600 m3/h
28 kPa 30 kPa
5.5 kW 7.5 kW
8.4 m2 8.4 m2
99,9 %
2.5 m2 2.5 m2
HEPA H13 HEPA H13
> 99.995 %
< 75 dB(A) < 75 dB(A)
DC 5800a 5.5 kW - 9
Capacity
kPa
40
20
5 kW
100 200
highly effi cient separator for larger particulate. Th e fi ne
dust is separated and contained by the unit's fi lter system.
Separated material is collected for disposal in the plastic
sack or container at the base of the cyclone.
Filter cleaning with reverse pulse gives long fi lter life and
constant capacity.
The container is attached to the machine by
two fasteners.
7.5 kW 60 Hz
300 400 500
m 3 /h
Part No 9481-B
