Thank you for choosing this Moulinex oven.
AP3 : Fan-assisted oven
AP4/DQ4 : Fan-assisted oven with rotisserie
AP5 : Fan-assisted oven with rotisserie, pre-
programme facility and interior light.
Description
Familiarise yourself with the various parts of
your Compact Turbo oven and its accessories.
Open out the diagram sheets inside the cover.
The red numbers correspond to the diagrams
of the various parts of your oven and are used
throughout the following pages.
1/ The Oven
1
A Door
A1 Door handle
B Top element
C Three cooking levels
S Bottom element
D Rotisserie drive (AP4/DQ4/AP5 models)
E Interior light (AP5 only)
R Air vents
V Locking device for heating element
2
2/ Control Panel
F Thermostat dial
G Temperature control light
H Timer (0-120 min)
I Defrost position(AP3/AP4/DQ4 models)
Defrost button (AP5 only)
J Pre-programme cooking button, from
0-12 hours
K Interior light button (AP5 only)
L Cooking guide for 1 kg of food
(AP3/AP4/DQ4 models)
3/ Accessories
3
O 2 reversible grill shelves
P Tray (drip pan)
Q Rotisserie unit (AP4/DQ4/AP5 models)
Q1 Spit
Q2 Forks
Q3 Brackets
Features
- Walls lined with a self-cleaning enamel
- 26-litre capacity
- Total power 1700 Watts
- Oven power: 1475 Watts
- Grill + Roast power: 1700 Watts
- Power consumption:
. Heating up to 175ºC
. Maintain at 175ºC for 1 h
. TOTAL
0.17 Kwh
0.62 Kwh
0.79 Kwh
10

Safety Recommendations

1/ Connection
Check that the voltage on the appliance rating
plate corresponds to the voltage on your mains
supply meter. For safety reasons it is essential
to connect your appliance to an earthed socket
which complies with electrical standards.
Avoid any electrical installation which does not
comply with them.
Any error in connecting the appliance
invalidates the guarantee.
Make sure your electric meter and fuse box
are marked 10 Amps. or more.
Wiring instructions for U.K and Ireland
only :
APPLIANCES WITH FITTED PLUG
Important : For your convenience this
appliance is supplied complete with a plug
incorporating a 13 amp fuse.
In the event of replacing a fuse in the plug
supplied, a 13 amp fuse approved by ASTA
to BS1362 must be used.
If the socket outlets are not of the 13A BS 1363
type, and therefore do not accept the plug
connected to this appliance, cut off the plug.
When cut off, this plug is a shock hazard if
inserted into a socket outlet and must
therefore be disposed of safely.
Fit the appropriate plug according to the ins-
tructions in paragraph "Fitting a plug". With
alternative plugs a 15 amp fuse must be fitted
either in the plug or adaptor or at the main
fuse box.
FITTING A PLUG - IMPORTANT
The wires in the mains lead are coloured in
accordance with the following code:
GREEN & YELLOW
BLUE: NEUTRAL - BROWN
As the colours in the mains lead of this
appliance may not correspond with the
coloured markings identifying the terminals in
your plug, proceed as follows:
The wire which is coloured GREEN &
YELLOW must be connected to the terminal
in the plug which is marked with the letter 'E'
or by the earth symbol
or green and yellow. The wire which is
coloured BLUE must be connected to the ter-
minal which is marked with the letter 'N' or
coloured black. The wire which is coloured
BROWN must be connected to the terminal
which is marked with the letter 'L' or coloured
red.
This appliance is manufactured to conform to
: EARTH
: LIVE
or coloured green
