Thank you for choosing an appliance from the
Moulinex range.
The oven you have chosen boasts an ultra
rapid preheating system, a conventional oven
and a grill (models CH2 and CH3 only)
Description
Familiarise yourself with the different parts
and accessories of you MaxiChef oven. Please
refer to the numbers in the margin below and
the figures on the inside cover.
1) The appliance
1
A Door
A1 Door handle
B Upper heating elements
C Lower heating elements
D Grill runners
E Safety hook
F Air vents
2 2) Control panel
G On/off button (CH1 and CH2 models)
H Thermostat control
I On/off indicator light
J Cooking guide (models CH1 and CH2)
K Grill position (models CH2 and CH3)
L Timer button (model CH3)
3) Accessories
3
M Reversible grill
M1 High position
M2 Low position
Grill Tray (according to model)
Crumb tray (optional)

Technical Data

- Aluminized interior walls
- Capacity: 10L
- Total power: 1500W
- Power: oven: 1500W grill: 750W
- Energy consumption:
. Preheating at 200°C
. For 1 hour at 200°C
. TOTAL:

Safety Advice

1) Recommendations
- Your appliance is for domestic use only, and
should only be used for the cooking of food
- Do not touch the hot surfaces, particularly
the window of the door, when the oven is in
use
4
0,06 kWh
0,37 kWh
0,43 kWh
9
- For safety reasons, keep children at a
safe distance from the oven
- Children should only use the oven under
parents' supervision and responsibility
- Stay near the oven when in use
- Do not place anything on the door when
open
- Do not cover the inside of the oven with alu-
minium foil, this will prevent the thermostat
working properly and you will thus risk
damaging the appliance
- If the appliance does not function properly
during use, disconnect it immediately and
enquire at a Moulinex approved service cen-
tre
- Disconnect the appliance as soon as you
finished using it
2) Connection
- Always check that the voltage of your
appliance matches that of your electrical ins-
tallation
- It is essential that your appliance is
connected using an earthed plug complying
with required electric standards.
Any error in connection will invalidate the
guarantee
- It is essential that your meter and fuse box
can withstand a minimum of 10 amps
Wiring instructions for U.K and Ireland
only :
APPLIANCES WITH FITTED PLUG
Important : For your convenience this appliance
is supplied complete with a plug incorporating
a 13 amp fuse.
In the event of replacing a fuse in the plug
supplied, a 13 amp fuse approved by ASTA to
BS1362 must be used.
If the socket outlets are not of the 13A BS 1363
type, and therefore do not accept the plug
connected to this appliance, cut off the plug.
When cut off, this plug is a shock hazard if
inserted into a socket outlet and must therefore
be disposed of safely.
If the fuse cover is detachable, never use the
plug with the cover omitted. Replacement
covers can be obtained from your service
agent.
Fit the appropriate plug according to the ins-
tructions in paragraph "Fitting a plug". With
alternative plugs a 15 amp fuse must be fitted
either in the plug or adaptor or at the main fuse
box.
