Overview of the appliance and scope of supply

• these user instructions
Before using for the fi rst time
❐ Keep children away from the packaging materials. There is a
danger of suffocation!
1. Take the appliance out of its packaging and check it for transportation damage. If you note
any damage, do not use the appliance (!); please contact our customer service department.
02078_DE-GB-FR-NL_V0.indd 16 02078_DE-GB-FR-NL_V0.indd 16
16
17
18
15
14
13
12
11
19
20
2. Insert the lower shaft (6) into the upper shaft (3), until you hear
an audible click as it engages.
1. Handle
2. Upper cable holder
1
3. Upper shaft
2
4. Lever to adjust the shaft length
3
5. Centre cable holder
6. Lower shaft with release button
4
7. Shaft holder
8. Water reservoir aperture with
locking cap
9. Release button (at the rear)
10. Cleaner base
5
11. Lower cable holder (at the rear)
6
12. Indicator lamp
13. Water reservoir
7
14. On/off switch
8
15. Carrying handle
16. Floor cloth for light soiling
9
17. Floor cloth with heavy-duty insert
for stubborn dirt
18. Floor tray
19. Measuring cup (260 ml)
20. Funnel
