7.2.7

Overall terminal diagram 1370-20 with 1370-40

The double page overleaf contains the terminal plan for a standard installation
with the power supply module 1370-40.
Connection variants and non-standard functions must be performed as indica-
ted in the terminal diagrams on the following/previous pages.
Only locking elements for 24 V DC rated operating voltage can be connected to
the control module.
Note:
Ensure correct connection! Incorrectly performed connections will result
in forfeiture of warranty cover.
All control and display elements and cables indicated in dotted lines in the
terminal diagrams denote optional connection.
The relevant VDE regulations as well as the stipulations of the local elec-
tricity utility company must be observed.
The entire system must permit isolation from the supply circuit by an
easily accessible disconnecting device.
71
