6.1 Settings

Audible A-opener / A-opener servo acoustic sound transmitter
The ex-factory setting of GU-SECURY Automatic with A-opener / A-opener servo is two signal
tones acknowledging the opening cycle and indicating to the user that the latchbolts are
completely retracted for access.
It is possible to deactivate these audible signals.
Deactivation is done as follows:
 After the lock's electric release (triggered by a potential-free contact), the lock must be
disconnected from the voltage supply, however, not earlier than 10 seconds after discon-
nection.
 The lock must be disconnected from the voltage supply for at least 10 seconds.
 Afterwards switch the power on again.
 Now a fi rst pulse must be given to the door release input within 2 seconds,
 and a second one immediately afterwards which has to last for at least 10 seconds.
Note: the motor is not operating meanwhile.
 After this the signal tones are deactivated.
In order to activate the signal tones, follow the same programming steps.

6.2 Trial run

After installation, check all functions in a trial run.
Attention!
Risk of injury when reaching between door leaf and frame!
When the installation is completed, the building operator/end user must be instructed in all
important operating steps.
In order to test the lock in a trial run, a pulse is given to the door release input (e.g. via
intercom). The motor retracts the latchbolts, and after approx. 1.5 seconds acknowledges open
status with signal tones. This is when the door can be opened by hand.
The latchbolts are retained for approx. 2 seconds. Afterwards the motor releases them again
and they extend to their initial position. Now the door can be closed again by hand.
Note for the A-opener servo

The servo function is activated only 10 s after switching on the
power supply.
For the trial run, the A-opener servo is activated by turning the key slightly towards the opening
direction, or by lightly touching the lever handle. The motor now retracts all of the latchbolts.
Note: With the GU-SECURY variants "AutomaticDay" and "AutomaticTE" with "daytime release
function", the latch of the central lock is not retracted by the A-opener!
The lock can always be operated mechanically by key from both sides. With the central
deadbolt retracted, door opening from inside via lever handle is possible at any time.
